Powerful Outdoor IoT GatewayPLUS in the LoRaWAN® Network EUROPE of ZENNER Connect GmbH The ZENNER IoT GatewayPLUS Outdoor for building LoRaWAN coverage and realising IoT use cases. The ZENNER IoT GatewayPLUS Outdoor uses the powerful LoRaWAN technology, whose excellent building penetration and wide-area network coverage ensure the connectivity of IoT sensors even under difficult environmental and installation conditions. The outdoor gateway is ideal for LoRaWAN network coverage in rural and urban areas to receive readings from multiple sensors. The device can be used across divisions for a wide range of IoT applications and is an integral part of the ZENNER IoT system solutions. With just a few gateways, entire cities can be covered. Thanks to the very robust housing made of painted aluminium, the outdoor gateway is very resilient to extreme weather conditions and is characterised by a high level of fail-safety. In addition to the two external LoRa antennas for the 16 Channels, the ZENNER IoT GatewayPLUS Outdoor also uses an external LTE antenna to ensure the best possible connection to the backend - provided there is no Ethernet connection. This feature is not found in comparable competitor products. The gateway ensures LoRaWAN reception of your LoRaWAN end devices in the gateway's reception area and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN network EUROPE. Like all data transmissions, this is of course secure and AES 128 encrypted. The GatewayPLUS OUTDOOR gives you access to the LoRaWAN® network EUROPE of ZENNER Connect. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client, which you receive after ordering, is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors). The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect EUROPE LoRaWAN® network, you only need to establish the power supply. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. The data transmission from your gateway to the backend system is carried out via the SIM card of ZENNER Connect included in the Gateway. If you are planning a larger project, please contact us. We will be happy to support and advise you individually. By the way: ZENNER includes everything you need to operate the gateway in the scope of delivery - from the mounting device to all antennas and cables. Scope of use ZENNER IoT GatewayPLUS Outdoor: With the ZENNER IoT GatewayPLUS Outdoor you receive LoRaWAN connectivity and data transmission in the ZENNER Connect network EUROPE for 12 months and use of up to 50 LoRaWAN IoT sensors. The gateway is part of the LoRaWAN network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider. Of course, you only receive the data of your own end devices! Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.   Associated User Agreement ZENNER IoT GatewayPLUS Outdoor: Please note: This corresponding associated user agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway.   LoRaWAN® network coverage ZENNER Connect: To the overview map of our network coverage: To the network coverage   NEW OPTIONAL: Order the B.One Gallery visualisation solution for 12 months and for 50 devices with ZENNER IoT PLUG&PLAY directly. In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be.   User agreement for the visualisation solution B.One Gallery: => Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen.   Exchange and inspiration in the B.One Community Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you! Join the B.One Community   Features and functions of the GatewyPLUS Outdoor: Suitable for LoRaWAN IoT solutions ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator. Gateway use ONLY in the following countries of the European Union: GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. Bidirectional LoRaWAN radio communication Secure encrypted data transmission end-to-end (AES 128) No storage of sensor data such as meter readings on the gateway LoRaWAN gateway modules according to reference architecture 1.5 Automatic switch from mobile radio (already included) to Ethernet backhaul possible, Attention! If the gateway is connected to an Ethernet connection, the customer establishes the data transmission from the gateway to the backend via his own Internet connection!  This may incur additional costs for the data transmission! Therefore, use the connection via the integrated mobile radio data card/SIM, which is already included. This way you will not incur any additional data transmission costs! Manufacturer's Declaration of Conformity including all applicable radio, low voltage and electricity regulations of Europe and RED (Radio Equipment Directive). Please note: The reception quality and range of your LoRaWAN gateway depends on the mounting or installation location you choose. For details, please refer to the installation instructions and the additional technical documentation. You need mobile radio coverage at the installation or mounting location of the gateway! Alternatively, a separate Ethernet connection. For operation, you need a standard 230V power connection/socket! Plug & Play - easy integration through pre-configured software Security patches and software updates are distributed automatically LoRaWAN gateway modules according to reference architecture 1.5 Automatic switch from mobile radio to Ethernet backhaul (if available) Manufacturer's Declaration of Conformity including all applicable radio, low voltage and electricity regulations of Europe and RED (Radio Equipment Directive) Application areas: Optimal for outdoor IoT use cases Smart City, Smart Parking, Smart Waste, Smart Lighting, ... e.g. monitoring of local network transformer stations; shaft meter reading Smart Industry, Retail, Logistics, SMB, Smart Agriculture & Farming, Asset Tracking... Scope of delivery: IoT Outdoor GatewayPLUS 2x LoRa antenna incl. antenna cable 1x LTE antenna incl. antenna cable 1x Ethernet cable (5m) Mounting device incl. pole mount PoE injector Potential equalisation cable (earthing cable) Cable tie Technical data: Mobile radio: Mini SIM - 2G, 3G (UMTS), 4G (LTE) - external LTE antenna Ethernet: RJ45 - priority over mobile radio LoRa channel: 16 channels - two external antennas TX power: max. 27 dBm (500 mW) conducted Frequency: EU-868 Power supply: Power over Ethernet (PoE) Antennas: External: 2 x LoRa, 1 x LTE (antennas incl. holder included in delivery) Protection class: IP67 Housing: Aluminium, lacquered Operating temperature: 0°C to +50°C Storage temperature: -40°C to +80°C Mounting: Wall, pole (bracket incl. earth cable included, galvanised steel) Maintenance: Remote firmware upgrades via ZENNER Cloud Certification: EN 301 489-3, EN 300 220-2

The LoRaWAN® gateway with 16 channels for the realization of IoT use casesCan be used in all LoRaWAN® networks / Power supply: Power over Ethernet (PoE)Discover the future of intelligent networking with the ZENNER IoT Gateway Outdoor 16! This powerful LoRaWAN® gateway not only offers you outstanding building penetration, but also comprehensive network coverage that ensures stable connectivity of your IoT sensors even under the most demanding conditions. Imagine how you can monitor and control your environment in real time - whether in rural areas or urban centers. With the ZENNER Gateway, this dream becomes a reality. Take advantage of a smart infrastructure and experience the ease of data transmission. Whether you want to monitor the air quality in your city or optimize the energy consumption in your building - the ZENNER IoT Gateway Outdoor 16 is your reliable partner on this journey.What makes this product unique? Its robustness and versatility! The painted aluminum housing withstands extreme weather conditions and ensures maximum reliability. The integration of two external LoRa antennas and an LTE antenna guarantees a first-class connection to the backend. The gateway also supports bidirectional communication with encrypted data transmission (AES 128) so that your information is always secure.The ZENNER IoT Gateway is not only a technical masterpiece, but also extremely adaptable. It can be easily integrated into a wide range of IoT applications, be it heat cost allocators, water or heat meters or even smart city projects such as parking sensors and air quality sensors. With just a few gateways, you can already cover entire cities and thus integrate numerous end devices into the LoRaWAN® wireless system. You can rely on the quality and experience of ZENNER. Our products are developed according to reference architecture 1.5 and support the Semtech Packet Forwarder to always offer you the best performance. In addition, there is an automatic switch from mobile radio to Ethernet backhaul when available - so you are always optimally connected.Performance characteristics in overviewSupport for the Basics StationSuitable for LoRaWAN® IoT solutionsBidirectional LoRaWAN® radio communicationEncrypted end-to-end data transmission (AES 128)No storage of meter readings on the gatewayFields of application in EuropeLoRaWAN®-Gateway modules according to reference architecture 1.5Support for the Semtech Packet ForwarderAutomatic change from mobile radio to Ethernet backhaul (if available)ApplicationsSmart City (Smart Parking, Smart Waste, Smart Lighting,…)Monitoring of local network transformer stationsReadout of shaft meters Asset TrackingScope of deliveryGateway - pre-assembled on assembly supportMounting bracket with nuts, spring ring and washers2x spacer sleeves for mounting bracket 2x 868 MHz LoRaWAN®-Antennas1x LTE broadband antenna3x Antenna cable Cable ties2x RJ45 PlugsEquipotential bonding cable (16 mm²)Network cable (5 m) mit PG cable glandPoE injectorPower cord for PoE injectorPoE injector Equipotential bonding cableTechnical dataCellular network: Mini SIM – 2G, 3G (UMTS), 4G (LTE) – external LTE antenna Ethernet: RJ45 – priority over cellular network # LoRa channel: 16 channels - two external antennas TX power: max. 27 dBm (500 mW) conducted Frequency: EU-868 Power supply: Power over Ethernet (PoE) Antennas external: 2 x LoRa, 1 x cellular network (antennas incl. mounting bracket included in scope of delivery) Protection class: IP67Housing: Aluminium, coated Operating temperature: -10 °C to +50 °C Storage: temperature: -40 °C to +80 °C Installation: Wall, pole (bracket incl. grounding cable included in scope of delivery, galvanized steel) Maintenance: Remote firmware upgrades Certification: EN 301 489-3, EN 300 220-2 Weight: approx. 4.1 kg

Kerlink Wirnet iStation 4G IoT LoRaWAN® Outdoor Gateway 868 including PoE Injector Kerlink Wirenet iStation is the next generation of gateways and with its 8 channel RX (125 kHz, multi Spreading Factor) + 1 channel RX (250KHz) or 500kHz, mono Spreading Factor) + 1 channel RX (FSK) for 10 channels RX + 1 channel TX it is more compact and powerful than its predecessor. Thanks to its long range, the Wirnet iStation enables a secure and robust connection between sensor and information system.The Wirnet Station series enables a robust and reliable network implementation under LoRaWAN® for M2M & IoT connectivity service providers.It forms the centrepiece of the IoT (Internet of Things) network solution and enables fast and secure data transmission between the connected object and the information system. Attention: Not compatible with the Helium network! Use Cases: Outdoor LoRaWAN Netzwerk Infrastructur PoE or external power supply for temporary site tests

Kerlink Wirnet iStation 4G IoT LoRaWAN® Outdoor Gateway 868 without PoE Injector Note:  An additional PoE adapter is required to operate the iStation! see (ArtNR: 169942) or choose the Art NR 173007 GW including  PoE Adapter Kerlink Wirenet iStation is the next generation of gateways and with its 8 channel RX (125 kHz, multi Spreading Factor) + 1 channel RX (250KHz) or 500kHz, mono Spreading Factor) + 1 channel RX (FSK) for 10 channels RX + 1 channel TX it is more compact and powerful than its predecessor. Thanks to its long range, the Wirnet iStation enables a secure and robust connection between sensor and information system.The Wirnet Station series enables a robust and reliable network implementation under LoRaWAN® for M2M & IoT connectivity service providers.It forms the centrepiece of the IoT (Internet of Things) network solution and enables fast and secure data transmission between the connected object and the information system. Attention: Not compatible with the Helium network! Use Cases: Outdoor LoRaWAN Netzwerk Infrastructur PoE or external power supply for temporary site tests

Powerful Indoor IoT Gateway in the LoRaWAN® network EUROPE from ZENNER Connect GmbHThis ZENNER IoT GatewayPLUS Indoor utilises the powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure the connectivity of IoT sensors even under difficult environmental and installation conditions.The gateway is ideal for receiving your LoRaWAN® devices and sensors within a building and in the immediate vicinity in order to receive the values of sensors that are sometimes difficult to access on several floors as well as in basements, garages, gardens and car parks - without any additional repeaters. The device can be used across all sectors for a variety of IoT applications.The ZENNER IoT GatewayPLUS Indoor has already been installed in over 30,000 LoRaWAN® system installations of the Minol ZENNER Group and is an integral part of many Minol ZENNER IoT system solutions. Thanks to its deliberately simple design, the gateway is barely noticeable in its surroundings.The gateway ensures the LoRaWAN® reception of your LoRaWAN® end devices in the gateway's reception area and transmits their data to the backend. In addition to receiving your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, this is of course secure and AES 128 encrypted.The GatewayPLUS Indoor gives you access to ZENNER Connect's LoRaWAN® network EUROPE for 12 months. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the ZENNER Datahub backend system. This means that you do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client that you receive after ordering is ultimately only required for the creation of sensors whose data you wish to receive via the gateway.The gateway is therefore already fully and permanently preconfigured and an integral part of the ZENNER Connect LoRaWAN® network; all you have to do is connect it to the power supply. With the gateway, LoRaWAN® data transmission from 50 of your own LoRaWAN end devices is included in the purchase price for 12 months. Data transmission from your gateway to the backend system takes place via the ZENNER Connect SIM card included in the gateway. If you are planning a larger project, please contact us, we will be happy to support and advise you individually.Scope of use ZENNER IoT GatewayPLUS Indoor:With the ZENNER IoT GatewayPLUS Indoor you get LoRaWAN® connectivity and data transmission in the ZENNER Connect LoRaWAN® network EUROPE for 12 months and use of up to 50 LoRaWAN® IoT sensors.The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception area of your gateway are received in encrypted form and transmitted to the network provider. Of course, you only receive the data from your own end devices!Due to network regulation within the European Union, the gateway can currently ONLY be used in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.User agreement ZENNER IoT GatewayPLUS IndoorPlease note: This associated user agreement (also to be found below under ‘Downloads’) is an integral part of the contract when purchasing this gateway.LoRaWAN® network coverage ZENNER Connect To the overview map of our network coverage: To the network coverageDISCOVER NOW: Order the B.One Gallery visualisation solution for 12 months and for 50 devices with ZENNER IoT PLUG&PLAY directly!Would you like to receive B.One Gallery access and view your sensor data visually on the visualisation platform? Then simply order the B.One Gallery as well. When you purchase the ‘B.One Gallery’ item, you receive access for 12 months and can link up to 50 sensors. You can find more information about the B.One Gallery here.User agreement for the B.One Gallery visualisation solution=> Please note when purchasing the B.One Gallery servicePlease note: This associated user agreement (also to be found below under "Downloads") is an integral part of the contract when purchasing the B.One Gallery (item number 801628).Exchange and inspiration in the B.One CommunityHave you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and want to exchange ideas? Or has your boss given you the task of immersing yourself in the Internet of Things? Then the new B.One Community is the right place for you! More about the B.One CommunityFeatures and functions of the GatewayPLUS IndoorSuitable for LoRaWAN® IoT solutionsZENNER Connect GmbH is the LoRaWAN® network operator for your gateway. This means that you do not need to register as an independent LoRaWAN® network operator. Gateway use ONLY in the following countries of the European Union: GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.Bidirectional LoRaWAN® wireless communicationSecurely encrypted end-to-end data transmission (AES 128) No storage of sensor data such as readings on the gateway LoRaWAN® gateway modules in accordance with reference architecture 1.5Automatic switch from mobile radio (already included) to Ethernet backhaul possible. Attention: If the gateway is connected to a LAN connection, the customer establishes the data transmission from the gateway to the backend via his own Internet connection! This may incur additional costs for data transmission! Therefore, use the connection via the integrated mobile phone data card/SIM, which is already included. This means you do not incur any additional data transfer costs! Please note: The reception quality and range of your LoRaWAN® gateway depends on the mounting or installation location you choose. For details, please refer to the installation instructions and further technical documentation.The average reception area within a building can cover up to 8-10 floors, depending on the nature of the building.The reception coverage outside the building in which the gateway is installed can be up to 1 kilometre. You need mobile phone coverage at the installation or mounting location of the gateway! Alternatively, a separate Ethernet connection. A standard 230V power connection/socket is required for operation.Manufacturer's declaration of conformity, including all applicable regulations on radio, low voltage and electricity from Europe and RED (Radio Equipment Directive)Areas of application Ideal for LoRaWAN® based IoT applications in buildings and in the building environment.Smart Building / Home / Office / School / ParkingSmart City / Smart IndustryIndoor air quality measurementTechnical dataMobile radio: Mini SIM - 2G, 3G (UMTS), 4G (LTE) - internal antenna Ethernet RJ45 - Priority over mobile radio Ethernet: RJ45 - priority over mobile radioLoRa Channel: 8 channels - internal antenna/-n TX power: max. 27 dBm (500 mW) conductedFrequency: EU-868 MHz Power supply: Internal power supply unitAntennas: Internal - 1 x LoRa, 1 x mobile radio Protection class: IP30Housing: Plastic with flame protection according to UL94-2013 Rev.9-2019, class: V-0Dimensions [L x W x H]: 18.4 x 12.7 x 4.8 cmOperating temperature: 0 °C to +50 °CStorage temperature: -40 °C to +80 °C LED: Power, LAN, CellularPre-configured and connected to the ZENNER Connect LoRaWAN® network (this is NOT changeable!)Mounting: Wall (bracket incl. screws and plugs included)Maintenance: Remote firmware upgrades are performed automaticallyCertification: EN 301 489-3, EN 300 220-2

Attention: The external antennas are not included in the scope of delivery and must be purchased separately!Antenna LoRa Antenna LTEPowerful indoor IoT gateway in the LoRaWAN® network EUROPE from ZENNER Connect GmbHThis ZENNER IoT GatewayPLUS Indoor uses the powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure the connectivity of IoT sensors even under difficult environmental and installation conditions. The gateway is ideal for receiving your LoRaWAN® devices and sensors within a building and in the immediate vicinity in order to receive the values of sensors that are sometimes difficult to access on several floors as well as in basements, garages, gardens and car parks - without any additional repeaters. The device can be used across all sectors for a variety of IoT applications. The ZENNER IoT GatewayPLUS Indoor has already been installed in over 30,000 LoRaWAN® system installations of the Minol ZENNER Group and is an integral part of many Minol ZENNER IoT system solutions. Thanks to its deliberately simple design, the gateway is barely noticeable in its surroundings. The gateway ensures LoRaWAN® reception of your LoRaWAN® end devices in the gateway's reception area and transmits their data to the backend. In addition to receiving your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, this is of course secure and AES 128 encrypted.The GatewayPLUS Indoor gives you access to ZENNER Connect's LoRaWAN® network EUROPE for 12 months. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the ZENNER Datahub backend system. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client that you receive after ordering is ultimately only required for the creation of sensors whose data you wish to receive via the gateway.The gateway is therefore already fully and permanently preconfigured and an integral part of the ZENNER Connect LoRaWAN® network; all you need to do is connect it to the power supply. With the gateway, LoRaWAN® data transmission from 50 of your own LoRaWAN end devices is included in the purchase price for 12 months. Data transmission from your gateway to the backend system takes place via the ZENNER Connect SIM card included in the gateway. If you are planning a larger project, please contact us, we will be happy to support and advise you individually.Scope of use ZENNER IoT GatewayPLUS IndoorWith the ZENNER IoT GatewayPLUS Indoor you receive LoRaWAN® connectivity and data transmission in the ZENNER Connect LoRaWAN® network EUROPE for 12 months and use of up to 50 LoRaWAN® IoT sensors.The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception area of your gateway are received in encrypted form and transmitted to the network provider. Of course, you only receive the data from your own end devices! Due to network regulation within the European Union, the gateway can currently ONLY be used in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.User agreement ZENNER IoT GatewayPLUS IndoorPlease note: This associated user agreement (also to be found below under ‘Downloads’) is an integral part of the contract when purchasing this gateway.LoRaWAN® network coverage ZENNER ConnectTo the overview map of our network coverage: To the network coverageDISCOVER NOW: Order the B.One Gallery visualisation solution for 12 months and for 50 devices with ZENNER IoT PLUG&PLAY directly!Sie möchten einen B.One Gallery Zugang erhalten und somit Ihre Sensordaten optisch aufbereit auf der Visualisierungsplattform einsehen? Dann bestellen Sie einfach die B.One Gallery mit dazu. Mit dem Kauf des Artikels "B.One Gallery" erhalten Sie einen Zugang für 12 Monate und können bis zu 50 Sensoren verknüpfen. Mehr Infos zur B.One Gallery finden Sie hier.User agreement for the B.One Gallery visualisation solution=> Please note when purchasing the B.One Gallery servicePlease note: This associated user agreement (also to be found below under ‘Downloads’) is an integral part of the contract when purchasing the B.One Gallery (item number 801628).Exchange and inspiration in the B.One CommunityHave you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and want to exchange ideas? Or has your boss given you the task of immersing yourself in the Internet of Things? Then the new B.One Community is the right place for you!Mehr zur B.One CommunityFeatures and functions of the GatewayPLUS IndoorSuitable for LoRaWAN® IoT solutionsZENNER Connect GmbH is the LoRaWAN® network operator for your gateway. This means that you do not need to register as an independent LoRaWAN® network operator.Gateway use ONLY in the following countries of the European Union: GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.Bidirectional LoRaWAN® wireless communication Securely encrypted end-to-end data transmission (AES 128)No storage of sensor data such as readings on the gateway LoRaWAN® gateway modules in accordance with reference architecture 1.5 Automatic switch from mobile radio (already included) to Ethernet backhaul possible. Attention: If the gateway is connected to a LAN connection, the customer establishes the data transmission from the gateway to the backend via his own Internet connection! This may incur additional costs for data transmission! Therefore, use the connection via the integrated mobile phone data card/SIM, which is already included. This means you do not incur any additional data transfer costs! Please note: The reception quality and range of your LoRaWAN® gateway depends on the mounting or installation location you choose. For details, please refer to the installation instructions and further technical documentation.The average reception area within a building can cover up to 8-10 floors, depending on the nature of the building.The reception coverage outside the building in which the gateway is installed can be up to 1 kilometre. You need mobile phone coverage at the installation or mounting location of the gateway! Alternatively, a separate Ethernet connection. A standard 230V power connection/socket is required for operation.Manufacturer's declaration of conformity, including all applicable regulations on radio, low voltage and electricity from Europe and RED (Radio Equipment Directive)Areas of applicationIdeal for LoRaWAN® based IoT applications in buildings and in the building environmentSmart Building / Home / Office / School / Parking Smart City / Smart IndustryIndoor air quality measurementTechnical dataMobile radio: Mini SIM - 2G, 3G (UMTS), 4G (LTE) - internal antenna Ethernet RJ45 - Priority over mobile radio Ethernet: RJ45 - priority over mobile radioLoRa Channel: 8 channels - internal antenna/-n TX power: max. 27 dBm (500 mW) conducted Frequency: EU-868 MHz Power supply: Internal power supply unitExternal antenna connections for: 1 x LoRa, 1 x mobile radioProtection class: IP30Housing: Plastic with flame protection according to UL94-2013 Rev.9-2019, class: V-0 Dimensions [L x W x H]: 18.4 x 12.7 x 4.8 cmOperating temperature: 0 °C to +50 °CStorage temperature: -40 °C to +80 °CLED: Power, LAN, CellularPre-configured and connected to the ZENNER Connect LoRaWAN® network (this is NOT changeable!)Mounting: Wall (bracket incl. screws and plugs included) Maintenance: Remote firmware upgrades are performed automaticallyCertification: EN 301 489-3, EN 300 220-2

Lean Wirnet iFemtoCell LoRaWAN Indoor Gateway from Kerlink The Wirnet iFemtoCell is a smart, configurable and performant indoor LoRaWAN gateway for smart IoT network. Based on LoRa technology, this gateway is perfectly designed for indoor public network extension (additional coverage in buildings to densify public network availability and continuity of service) or for ad-hoc indoor private coverage, like manufacturing, logistics or industrial sites requiring continuous connectivity for their IoT applications. Available in most global unlicensed frequency bands (like ISM ones), this cost-effective gateway is proposed through a compact and full featured casing. Easy to configure, it offers multiple options for backhaul like Ethernet, WiFi or WAN. Used as a hub to connect end devices, it can power various in-building enterprise applications like assets monitoring, energy consumption control, security enforcement or any other operation-critical data collection in various environment (buildings, factory, industrial sites, farms, harbors, airports, mines, ...). This LoRaWAN gateway leverages the same successful LoRa RF technical design as its carrier-grade predecessor, the Wirnet Station, and offers high performance for very deep indoor coverage in demanding environments (basement, underground, parking, elevators shafts…) to connect energy meters, parking sensors or equipment actuators. This long-range and low-power gateway offers 49 LoRa demodulators over 9 channels and comes with exclusive features for its remote monitoring and management with Kerlink network operations solutions, the Wanesy Management Center. The Wirnet iFemtoCell is also compatible with the Wanesy Small Private Network solution to deploy standalone and self-operating LoRaWAN private network. Attention: Not compatible with the Helium network! Strengths: Carrier grade, robust, modular and scalable indoor LoRaWAN Gateway Low Power consumption and Wide Area coverage (15+km in semi-urban area and 2km in urban area) High capacity and reliability, for deep indoor bidirectional communications handling high volumes of end-points and messages. Light infrastructure, easy to install and fast to configure. High interferences-resistance with built-in band bass filters for better data transmission and permanent high availability. Technical features: CPU & Memory: Powerful processor ARM processor with hardware watchdog and optimized power consumption management DDRAM 256 MB / 8 GB eMMC Operating System: LoRa Packet Forwarder, Linux OS, embedded base station controller (Wanesy Management Center remote management) Software packages and development tools included Networking: Firewalling, routing, networking and tunneling features Security: Secure boot, trust zone, firewall, software auto-recovery and secure firmware remote upgrade. Mechanical: Quality plastic enclosure, weight less than 500 g. RJ45, Jack, SMA/RP-SMA, USB port and host secure interface Power: Power supply 230VAC/12VDC with provide connector Communication: 49 LoRa demodulators over 9 channels. Omnidirectional 3 dBi external antenna. Wide coverage and very deep indoor coverage (undergrounds, basements, lifts shafts…) based on LoRa specifications. Supported ISM bands: EU 863-870 MHz, India 865-867 MHz, US 902-928 MHz FCC, AS 923 MHz. Backhaul connectivity over Ethernet, WLAN with built-in antenna. WWAN in option (USB dongle). Environment: Full operating range, humidity tolerance for indoor use only. Certified for Ingress protection / Impact Resistance / Flammability rating. Remote management: Remote alarm notification, firmware upgrade, file transfer, configuration, radio monitoring and statistics (Wanesy Management Center) Certification: EU / FCC / IC / ETSI certified.

Wirnet iFemtoCell-evolution Indoor LoRaWAN Gateway from Kerlink The Wirnet iFemtoCell-evolution is a small configurable, high performance LoRaWAN gateway for smart IoT networks. The device is especially designed for the extension of public networks indoors or for private IoT networks. The device can be used across industries for a wide range of IoT applications. Use the device to implement your Smart City, Smart Home, Smart School projects (and much more) - wherever a reliable and permanent supply of LoRaWAN is required or you want to consolidate your existing network. The cost-efficient gateway with compact form factor is easy to configure and can be used with different backhaul connections: Mini-SIM - 4G Worldwide Module (with 3G/2G fallback) with integrated LTE antenna Ethernet (RJ45) This is also the main difference between the iFemtoCell-evolution and its sister product iFemtoCell, which enables a WiFi connection instead of the 3G/4G backhaul. Attention: Not compatible with the Helium network! Special Features: Robust, modular and scalable indoor LoRaWAN gateway Low power consumption and long range (15+ km in semi-urban areas and 2 km in urban areas) High capacity and reliability for bi-directional indoor communications processing large volumes of endpoints and messages Easy to install and quick to configure using the same software as Wirnet iStation High immunity to interference due to built-in band-pass filters for better data transmission and permanent high availability Secure hardware and software architecture: SecureBoot (signed Firmware) Secure storage (keys and certificates in the secure area) using the ProvenCore™ solution Secured connections and backhaul protection (OpenVPN/IPsec) Reboot (watchdog) and restore the previous management configuration (or factory configuration if the boot problem cannot be solved)

Powerful Indoor GatewayPLUS SMART in the LoRaWAN® Network EUROPE of ZENNER Connect The ZENNER IoT GatewayPLUS SMART uses powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure connectivity of IoT sensors even under difficult environmental and installation conditions. This indoor gateway is ideally suited for receiving your LoRaWAN® devices and sensors inside a building and in the immediate vicinity, in order to receive the values of sometimes difficult-to-access sensors on several floors as well as basements, garages, gardens, car parks - all without additional repeaters. It can be used across all sectors for a wide range of IoT applications. The smart gateway ensures the LoRaWAN® reception of your LoRaWAN® end devices in the reception area of the gateway and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, of course, secure and AES 128 encrypted. The GatewayPLUS SMART gives you access to the ZENNER Connect LoRaWAN® network EUROPE. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client that you receive after ordering is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors). The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect LoRaWAN® network EUROPE, you only need to establish the power supply, connect the gateway to your WLAN and you can start immediately. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. Data transmission from your gateway to the backend system via your WLAN connection may incur additional costs. If you are planning a larger project, please contact us. We will be happy to provide you with individual support and advice. Scope of use ZENNER IoT GatewayPLUS SMART: With the ZENNER IoT GatewayPLUS SMART you receive LoRaWAN® connectivity and data transmission via your Wi-Fi in the ZENNER Connect LoRaWAN® network EUROPE for 12 months and use of up to 50 LoRaWAN® IoT sensors. The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider via your Wi-Fi! Of course, you only receive the data of your own end devices! Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. User Agreement ZENNER IoT GatewayPLUS SMART: Please note: This associated user agreement (also to be found below under "Available Downloads") is part of the contract when purchasing this gateway.   LoRaWAN® network coverage ZENNER Connect: To the overview map of our network coverage: https://www.mz-connect.com/netzabdeckung/   NEW OPTIONAL: Order the B.One Gallery visualisation solution for 12 months and for 50 devices with ZENNER IoT PLUG&PLAY directly. In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be.   User agreement for the visualisation solution B.One Gallery: => Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen.   Exchange and inspiration in the B.One Community Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you! Join the B.One Community   Features and functions of GatewayPLUS Smart Suitable for LoRaWAN® IoT solutions ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator. Gateway use ONLY in the following countries of the European Union:GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. Bidirectional LoRaWAN® radio communication Secure encrypted data transmission end-to-end (AES 128) No storage of sensor data such as meter reading values on the gateway LoRaWAN® gateway modules according to reference architecture 1.5 Connection to the backend with available WLAN network.Attention: The customer establishes the data transmission from the gateway to the backend via his own internet connection. This may incur additional costs for data transmission. Please note: The reception quality and range of your LoRaWAN® gateway depends on the installation location you have chosen. For details, please refer to the installation instructions or the User Guide. The average reception coverage inside a building can be up to 8-10 floors, depending on the building characteristics. The reception coverage outside the building where the gateway is mounted can be up to 1 kilometer. You will need WLAN connectivity at the gateway's mounting location. For operation you need a standard 230V power connection/socket. Declaration of Conformity (CE) and RoHS standards are complied with. Areas of application: Optimal for LoRaWAN® based IoT applications in buildings as well as in the building environment. Smart Building / Home / Office / School / Parking Indoor air quality measurement Submetering Technical data: Backhaul: Wi-Fi 802.11 b/g/n, frequency band: 2.4 GHz, security: WPA/WPA2 LoRa Channel: 8 channels, receive sensitivity: -140dBm, internal antenna TX power: up to +20dBm Frequency: EU-868 (862 - 870MHz) Power supply: 230V power outlet (Euro plug) / USB Type-C (900mA). Antennas: Internal - 1 x LoRa, 1 x Wi-Fi Protection class: IP40 Housing: Plastic with flame retardant according to UL94-2013 Rev.9-2019, class.: V-0 Dimensions [L x W x H]: 100 x 82 x 38 mm Weight: 160g Operating temperature: 0 °C to +40 °C Storage temperature: -40 °C to +70 °C LED: Wi-Fi status Preconfigured and connected to the ZENNER Connect LoRaWAN® network.(this is NOT changeable!) Mounting: power socket Standards: CE, RoHS

Optional Kerlink antenna set with 3dBi rod antenna for the Wirnet iStation. The LoRaWAN gateways of the iStation series from Kerlink have an integrated antenna as standard ex works. If the range of the internal antenna is not sufficient in practice, an external antenna can be retrofitted with this antenna set. The waterproof rod antenna (IP66K) is lightweight, has DC lightning protection and can be used under all conditions (e.g. strong winds). Scope of delivery: Rod Antenna 3 dBi Universal bracket 1 m coaxial cable

LoRaWAN® antenna (2.5/3 dBi) for connection to the TEKTELIC KONA Macro Outdoor Gateway. The antenna is omnidirectional with high gain and vertical polarization, designed for LoRa applications in the European 863-870 MHz ISM band. Product features: Omnidirectional pattern (360° in the horizontal plane) Vertical polarization Dipole radiation element 2.5 dBi gain For further information please refer to the data sheet in the download area below.

Citel surge protection PoE LAN surge protection RJ45 for Power-over-Ethernet  Protection against overvoltage in information technology networks 2-stage protection circuit with gas dissipators and low-capacitance semiconductors Product Details: Compatible with 10BaseT/100BaseT/1000BaseT networks Ideal protection level for network applications CAT5, Meets IEC 61643-21 standard Dimensions: 44 x 34 x 54 mm

Citel surge protector coax for antennas Coaxial surge protection with integrated gas arrester Protection of sensitive antenna applications against lightning strikeCoaxial connection with exchangeable gas arrester and earthing via M6 screw Product Details: Coaxial overvoltage protection - DC up to 4 GHz• Low signal loss and bidirectional protection Waterproof housing Dimensions: 68 x Ø16,2 mm

PoE Injector from LevelOne for the TEKTELIC KONA Macro Outdoor Gateway. Dieser PoE Injektor wird als Zubehör für die Nutzung des KONA Macro LoRaWAN® Outdoor Gateways benötigt. Letzteres finden Sie nachfolgend im Reiter "Zubehör". It uses Power over Ethernet (PoE) technology, which enables devices to be supplied with power and data simultaneously via their network connection. The PoE injector, or PoE adapter, thus enables the power supply of LoRaWAN® gateways via network connection. A PoE injector is thus a smart solution for supplying power to low-power devices that need to be placed in locations where no power outlet is available.

Antenna cable N-Male to N-Female for TEKTELIC KONA Macro IoT Gateway Very robust outdoor antenna cable with N-Type Male to Female connectors - suitable for the TEKTELIC KONA Macro Outdoor Gateway and the 2.5/3 dBi LoRaWAN® antenna.

Antenna cable for Kerlink Wirnet I-Station, 1m, N-Male x 2  Very robust antenna cable for Kerlink Wirnet I-Station (SAP 169942) 1m, N-type male to N-type male compatible with antenna for WIRNET I-Station 6db (SAP 169944).
