Optical Impulse Adapter Flash'O LoRaWAN® from WATTECO Pulse meter for the remote reading of gas, water, energy or heat meters with optical pulse output.  Configurable transmission: Interval, Thresholds & Batch Report.

WATTECO Digital I/O Adapter LoRaWAN® Class A IN'O is a LoRaWAN® Class A device from WATTECO transforming any type of binary I/O sensor into a remote wireless sensor that monitors and controls industrial equipment status.LoRaWAN® adapter for reading and interacting with isolated contacts. Simultaneous monitoring and control of up to 10 inputs and 4 outputs. Configurable transmission: Interval, Thresholds & Batch Report. Technische Spezifikationen: 10 on/off inputs (9-15V, max. 300mW) 4 opto-isolated outputs Battery (up to 12 years) or external power supply 9-24V Protection class: IP55 Dimensions: 85x82x85mm RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN®, Class A Transmission cycles: 10mn, 1h, 12h or defined by network Data history available Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 INPUT CHARACTERISTICS Number of inputs: 10 Impedance (M?): >1 Capacitance (nF): 1; typical Voltage (V): 0 - 30 Current (µA): 3.5 Frequency (Hz): 1-100 OUTPUT CHARACTERISTICS Number of Outputs: 4; optically isolated Open Collector: 250mW, Icc=500mA Voltage: 15V POWER Power supply: 3,6V / 3600mAh lithium battery 9V-15V / 300mW external power supply Autonomy within a +10°C to +25°C temperature range: 10 years for 1 measurement & 1 transmission per day INTERFACE LED Indicator: 3 LEDs for Configuration, Network pairing & Activity on inputs Magnetic Switch: Reset, ON/OFF MECHANICAL FEATURES  Dimension (mm): 84x82x85  IP Class: IP55 ENVIRONMENTAL Operating temperature (°C): -20 / +50 Storage temperature (°C): -10 / +30  DIRECTIVES & STANDARD EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE, FCC part 15.247 subpart C, RoHS recommendation compliant

Analogue Adapter Press'O LoRaWAN® Class A from WATTECO Press'O from WATTECO is a LoRaWAN® Class A device transforming any gauge type of 0-10V, 4-20mA analog sensor into a remote wireless sensor that monitors, controls, and radio transmit any fluid level (water, oil, gaz, …)Monitoring and control of 2 analog inputs and configurable transmission (interval, threshold values & batch report).

WATTECO Digital I/O Adapter LoRaWAN® Class C IN'O is a LoRaWAN Class A device transforming any type of binary I/O sensor into a remote wireless sensor that monitors and controls industrial equipment status.LoRaWAN adapter for reading and interacting with isolated contacts. Simultaneous monitoring and control of up to 10 inputs and 4 outputs. Configurable transmission: Interval, Thresholds & Batch Report. Product Details: 10 on/off inputs (9-15V, max. 300mW) 4 opto-isolated outputs External power supply 9-24V Protection class: IP55 Dimensions: 85x82x85mm RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN, Class C Data history available Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 INPUT CHARACTERISTICS Number of inputs: 10 Impedance (M?): >1 Capacitance (nF): 1; typical Voltage (V): 0 - 30 Current (µA): 3.5 Frequency (Hz): 1-100 OUTPUT CHARACTERISTICS Number of Outputs: 4; optically isolated Open Collector: 250mW, Icc=500mA Voltage: 15V POWER Power supply: 3,6V / 3600mAh lithium battery 9V-15V / 300mW external power supply Autonomy within a +10°C to +25°C temperature range: 10 years for 1 measurement & 1 transmission per day INTERFACE LED Indicator: 3 LEDs for Configuration, Network pairing & Activity on inputs Magnetic Switch: Reset, ON/OFF MECHANICAL FEATURES  Dimension (mm): 84x82x85  IP Class: IP55 ENVIRONMENTAL Operating temperature (°C): -20 / +50 Storage temperature (°C): -10 / +30  DIRECTIVES & STANDARDS EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE, FCC part 15.247 subpart C, RoHS recommendation compliant

LoRaWAN® IP55 Impulse Adapter from WATTECO with 3 Inputs Pulse Sens’O is a LoRaWAN sensor radio transmitting data from any pulse meters: water, gas, electricity, energy. Up to 3 devices per sensor can be connected. Configurable transfer (interval, threshold values & batch report)

Watteco Smart Plug LoRaWAN® Radio Socket for energy monitoring Smart Plug is a LoRaWAN® Class C smart home device that monitors, controls, reports, home's electronics appliances connected and electrical line quality. Product Details: Up to 3,500W and 16A Monitoring & Report: Power, Energy, Voltage & Frequency Power supply via mains voltage Dimensions 114x62x40mm RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN®, Class C Transmission cycles: 10mn, 1h, 12h or defined by network Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 ELECTRICAL Operating voltage (VAC): 100-250 Power frequency (Hz): 50-60 Max load capacity: 16A/250VAC POWER METER Active/Reactive Power resolution (W / Var): 1 Active/Reactive energy resolution (W.h / Var.h): 1 Power accuracy: < 1% above 40W >1% below 40W Energy measurement bandwidth: 1,23kHz QUALITY LINE INDICATOR Frequency: current/min/max values RMS Voltage: current/min/max values Over voltage: Number of occurrence the voltage exceed the overvoltage threshold Sag: Number of occurrence the main voltage is lower than the “Sag voltage Threshold” for at least the number of half cycle defined by the “Sag cycle Threshold” attribute INTERFACE LED Indicator: Configuration and pairing Button: Reset, ON/OFF MECHANICAL FEATURES  Dimension (mm): 62x114x40 Plug Type: Europe (optional US version) ENVIRONMENTAL Operating temperature (°C): -20 / +50 DIRECTIVES & STANDARDS EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE, FCC part 15.247 subpart C, RoHS recommendation compliant

WATTECO Impulse Adapter (3 Inputs) Pulse Sens'O LoRaWAN® IP55 with ATEX explosion protection Pulse Sens’O is a LoRaWAN sensor radio transmitting data from any pulse meters: water, gas, electricity, energy.Up to 3 devices per sensor can be connected. Configurable transfer (interval, threshold values & batch report) Details: 3 Pulse Inputs, 0-30V Lithium-Battery 3.6V, 3,6Ah Battery life up to 12 years Protection class: IP55; optional Outdoor IP68 and/or AteX Zone 2 Dimensions 85x82x55mm RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN, Class A Transmission cycles: 10mn, 1h, 12h or defined by network Data history available Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 SENSOR INPUT Number of inputs: 3 Impedance (M?): >1 Capacitance (nF): 1; typical Voltage (V): 0 - 30 Current (µA): 3.5 Frequency (Hz): 1-100 POWER Power supply: 3,6V / 3600mAh lithium battery ATEX certified (optional) Autonomy within a +10°C to +25°C temperature range: 12 years for 1 measurement & 1 transmission per day INTERFACE LED Indicator: 3 LEDs for Configuration, Network pairing & Activity on inputs Magnetic Switch: Reset, ON/OFF Cable connection:  IP55: cable connected inside the box. IP68: 1,5m cable length (The free end of the cable must be connected in an area that is protected from moisture) MECHANICAL FEATURES  Dimension (mm): 84x82x85  IP Class: IP55 or IP68 available ENVIRONMENTAL Operating temperature (°C): -20 / +50 Storage temperature (°C): -10 / +30  DIRECTIVES & STANDARDS EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE and RoHS recommendation compliant

LoRaWAN® Outdoor Remote Temperature Sensor from WATTECO Sensor with remote temperature probe. The Remote Temperature Sensor from WATTECO is a robust, battery-powered sensor for real-time transmission of temperature measurements over long distances via LoRaWAN®. Transmission of extensive area measurements, e.g. cold chains, refrigerated transports, smart buildings, industrial plants. Periodic transmission of the sensor values and/or alarm in case of exceeding or falling below the limit values. Use Cases: HVAC Monitoring of cooling suuply chains and refrigerated transporters Warehouse logistics with temperature-sensitive products Industrial processes (machinery, plant engineering) Data center / IT server room Technical specifications: Probe with 5m cable and metal tip Measuring range -40°C +90°C Precision -/+ 1°C - 30°C a +60°C Batch reporting via data compression  IP55 CE Compliant & RoHS Compliant Per request available with 2 measuring probes. RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN®, Class A Measurement Cycles from 1h to 48h in 1h step Data history available Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 TEMPERATURE MEASURE Range -40 / +90 Accuracy +/- 1°C over the range [-20°C; +40°C] Resolution 0.2°C OUTPUT CHARACTERISTICS 4-20mA gauge voltage supply (V): 10 0-10V gauge voltage supply (V): 14 POWER Power supply: 3,6V / 3600mAh lithium battery 12 years: Data compressed / 1 measure per hour / 1 transmission per day 9 years: Data not compressed / 1 measure per hour / 1 transmission per day INTERFACE Buzzer Indicator: Network pairing & configuration Magnetic switch: Reset, ON/OFF MECHANICAL FEATURES  Dimension (mm): 84x82x55 IP Class: IP55 DIRECTIVES & STANDARDS EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE, FCC part 15.247 subpart C, RoHS recommendation compliant

Energy data acquisition via LoRaWAN® with the WATTECO Intens'O Sensor/Adapter Intens'O is a LoRaWAN® sensor that measures the intensity of electrical power and determines the state of the equipment regarding a configured power threshold. The data is transmitted over a public or private LoRaWAN® radio network. Use Cases:  Remote monitoring of escalators in railway stations Faulty public lighting system detection Predictive maintenance of rotating machine Abnormal overconsumption monitoring, … Intens'O analyses the current magnitude of any electrical conductor. The current magnitude is measured thanks to a split core current transformer without disrupting the current path.Intens'O regularly measures the current magnitude and periodically transmits the operating status of the equipment. When the current magnitude is crossing a threshold previously set by the user , the sensor automatically transmit an alert with the associated current measurement. The alert can be transmitted from a public or private LoRaWAN communication network.Intens'O is quickly and easily placed on the power phase conductor of any control cabinet or of the electrical motor of the equipment for instance.It enables to check: If the equipment is operating or down, due to a mechanical failure for instance Whether the street light is operating properly or not in order to quickly replace the street lamp Up to 7 different current thresholds can be set by the user. When used in a building or in a factory for instance, It enables to set up a predictivemaintenance service Intens'O is easy to use, deploy and maintain. The sensor is equipped with: A split core current transformer A 3m cable allowing the current clamp to be placed on the live conductor in the electrical panel, close to the motor. The sensor can be remote to be located in the optimal radio coverage area, A 3M Dual Lock adhesive and adaptable hitching system An NFC identification tag (product number, serial number, production batch) A magnetic switch and a buzzer that allow the installer to easily enable / disable the sensor. The sensor is powered by a 3.6Volt lithium battery. The autonomy is more than 10 years when measuring current magnitude every 1 minute and when transmitting data every hour

LoRaWAN® WATTECO Atm'O Outdoor Radio Weather Station This Sensor from WATTECO is measunring outdoor temperature, relative humidity and atmospheric pressure.   Technical details: LoRaWAN®, Class A Temperature range: -20°C to +55°C Measurement of temperature, relative humidity and air pressure Vertical antenna Protection class: IP68 for outdoor use

WATTECO Impulse Radio Adapter Pulse Sens'O  LoRaWAN® (3 inputs) with ATEX explosion protection Pulse Sens’O is a LoRaWAN sensor radio transmitting data from any pulse meters: water, gas, electricity, energy.Up to 3 devices per sensor can be connected. Configurable transfer (interval, threshold values & batch report) Product Details: 3 Pulse Inputs, 0-30V Lithium-Battery 3.6V, 3,6Ah Battery life up to 12 years Protection class: Outdoor IP68 and AteX Zone 2 Dimensions 85x82x55mm RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN, Class A Transmission cycles: 10mn, 1h, 12h or defined by network Data history available Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 SENSOR INPUT Number of inputs: 3 Impedance (M?): >1 Capacitance (nF): 1; typical Voltage (V): 0 - 30 Current (µA): 3.5 Frequency (Hz): 1-100 POWER Power supply: 3,6V / 3600mAh lithium battery ATEX certified Autonomy within a +10°C to +25°C temperature range: 12 years for 1 measurement & 1 transmission per day INTERFACE LED Indicator: 3 LEDs for Configuration, Network pairing & Activity on inputs Magnetic Switch: Reset, ON/OFF Cable connection:  IP55: cable connected inside the box. IP68: 1,5m cable length (The free end of the cable must be connected in an area that is protected from moisture) MECHANICAL FEATURES  Dimension (mm): 84x82x85  IP Class: IP55 or IP68 available ENVIRONMENTAL Operating temperature (°C): -20 / +50 Storage temperature (°C): -10 / +30  DIRECTIVES & STANDARDS EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE and RoHS recommendation compliant

Robust LoRaWAN® Sensor from WATTECO with external temperature probe and 5 m cable  The Cels'O Sensor from WATTECO is a robust, battery-powered IP 66 capable sensor for real-time transmission of temperature measurements over long distances via LoRaWAN. Monitoring of temperature-sensitive products in cold chains and temperature-controlled supply chains. Periodic transmission of the sensor values and/or alarm in case of exceeding or falling below the limit values.   Use Cases: Monitoring of the ambient temperature in cooling and climatic chambers in the agricultural and food industry Applications: refrigerator, freezer, refrigerated vehicles and refrigerated containers Temperature-controlled supply chains Share information in the cloud

LoRaWAN door contact sensor Clos'O 868 MHz. Clos'O is a LoRaWAN® Sensor that determines if a gate is properly closed. Installed on the frame (or on the fixed part, it detects the position of a magnet fixed on the gate moving part. The sensor reports on a public or private LoRaWAN® radio network the open or closed state of the gate. An alert is transmitted if the sensor is dismantled. Use Cases for LoRaWAN door contact sensor Clos'O: checking the opening status of gates, portals, garage doors, etc. continuous monitoring of gates in fences along free surfaces on properties, near freeways, railroads and industrial sites Features and functions: LoRaWAN®, Class A autonomous sensor Detection distance: up to 35 mm Alarm on removal of the sensor very easy installation more than 5 years autonomous operation designed for outdoor use 868 MHz (other frequencies on request)

LoRaWAN® multi-room sensor TH from WATTECO for measuring temperature and humidity. The Temperature-Humidity sensor is a LoRaWAN® Class A wireless sensor device that measures and transmit over long distance temperature and humidity. Unobtrusive design and easy wall mounting (also temporary installation). Technical Details: Temperatur, Humidity Accuracy: ± 0.5°C, ±5%rh, Auflösung: 0,2°C, 0,5%rh Battery life approx. 5-10 years (depending on configuration) Dimensions 80x80x25mm RF TRANSCEIVER Frequency (MHz) EU: 863-870 Transmit Power (dBm) +14 Receiver Sensitivity (dBm) -140 FIRMWARE Protocol: LoRaWAN®, Class A Transmission cycles: 10mn, 1h, 12h or defined by network Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 TEMPERATURE MEASURE Accuracy (°C): +/- 0,5 Resolution (°C): 0,1 Range (°C): 0 / +40 HUMIDITY MEASURE Accuracy (%): +/- 5 Resolution (%): 0,5 Range: (%rH) 0 / 100 ALARMS Temperature: Min/Max value (Programmable from 0°C to 40°C in 1°C step) Humidity: Min/Max value (Programmable from 0%rH to 100%rH in 1%rH step) ON/OFF Anti-tamper: Against opening and detachment POWER Power supply: 3,6V / 3600mAh lithium battery Autonomy within a +10°C to +25°C temperature range: 5 years: 2 measures / hour and 1 transmit / day 9.5 years: 1 measure / hour and 1 transmit / day 23 years:8 measures / day and 1 transmit / day INTERFACE Network pairing & configuration Switches: Reset, ON/OFF MECHANICAL FEATURES  Dimension (mm): 80x80x25 ENVIRONMENTAL Operating temperature: (°C) 0 / +40 Storage temperature: (°C) +10°C / +30°C ; +20%rH / +60%rH DIRECTIVES & STANDARDS EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE, RoHS recommendation compliant

Pulse Sens’O is a LoRaWAN sensor radio transmitting data from any pulse meters: water, gas, electricity, energy.Up to 3 devices per sensor can be connected. Configurable transfer (interval, threshold values & batch report) Details: 3 Pulse Inputs, 0-30V Lithium-Battery 3.6V, 3,6Ah Battery life up to 12 years Protection class: IP55; optional Outdoor IP68 and/or AteX Zone 2 Dimensions 85x82x55mmRF TRANSCEIVERFrequency (MHz) EU: 863-870Transmit Power (dBm) +14Receiver Sensitivity (dBm) -140FIRMWAREProtocol: LoRaWAN, Class ATransmission cycles: 10mn, 1h, 12h or defined by network Data history available Activation method: Activation by Personalization (ABP) Over-The-Air Activation (OTAA) Data encryption: AES128 SENSOR INPUTNumber of inputs: 3 Impedance (M?): >1 Capacitance (nF): 1; typical Voltage (V): 0 - 30 Current (µA): 3.5 Frequency (Hz): 1-100 POWERPower supply: 3,6V / 3600mAh lithium battery ATEX certified (optional) Autonomy within a +10°C to +25°C temperature range: 12 years for 1 measurement & 1 transmission per day INTERFACELED Indicator: 3 LEDs for Configuration, Network pairing & Activity on inputs Magnetic Switch: Reset, ON/OFF Cable connection: IP55: cable connected inside the box. IP68: 1,5m cable length (The free end of the cable must be connected in an area that is protected from moisture) MECHANICAL FEATURESDimension (mm): 84x82x85 IP Class: IP55 or IP68 available ENVIRONMENTALOperating temperature (°C): -20 / +50 Storage temperature (°C): -10 / +30 DIRECTIVES & STANDARDEN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE and RoHS recommendation compliant
