ZENNER IoT PLUG&PLAY Use case: Room climate

3_Indoor_Climate_ZENN_Keyvisual_1220x463_IOT_PLUG-PLAY_RZ

ZENNER IoT PLUG&PLAY indoor climate

With the new simple ZENNER IoT PLUG&PLAY comfort solution, you can ensure optimum monitoring of indoor climate conditions. Monitor the optimum indoor climate at workstations, whether in the office or meeting room, in the shop, workshop, warehouse or pantry. Optimum indoor climate conditions promote concentration and performance, contribute to a better working environment and the well-being of colleagues and employees. The optimum temperatures and humidity levels for goods and products in warehouses and storerooms can also be easily monitored remotely. A modular and easily retrofittable solution for many possible applications in all kinds of rooms. Combine sensors with different measuring functions and simply select the sensors that measure and monitor what is important to you in the room in question. Temperature, humidity, Co2, brightness, movement. You also want to know whether rooms are or were occupied, whether windows and doors are open or closed. Then simply add further IoT PLUG&PLAY sensors to your room climate monitoring system as required, door and window contacts, motion detectors, brightness, leaks, smoke detectors... and stay informed at all times about whether not only the indoor climate in your company is right, but also whether everything else in the rooms is in order.

All ZENNER IoT PLUG&PLAY solutions are already fully developed and integrated in the B.One Gallery. Simply select all the necessary components for your use cases. The great thing is that all IoT PLUG&PLAY sensors, regardless of the use case, can be combined with each other and are displayed directly in the B.One Gallery as soon as the sensor data is received. For all applications, even in combination, normally only 1 GatewayPLUS (per building) and only one B.One Gallery is required. Order, unpack, plug in, run! That's ZENNER IoT PLUG&PLAY. IoT is this simple and modular.

With ZENNER IoT PLUG&PLAY, you save yourself the costs of complex post-installation of building cabling and expensive conversions. The sensors transmit via LoRaWAN® radio through ceilings and walls and deliver the measurement data to your B.One Gallery. As with all ZENNER IoT PLUG&PLAY solutions, you can add your sensors purchased in our shop manually by yourself into your LoRaWAN network EUROPE from ZENNER Connect (ZC) GmbH and your B.One Gallery. There you can easily and simply manage and visualise your LoRaWAN® sensors.

Visualisation of the sensor data in the B.One Gallery

Order, plug in, switch on and visit your B.One Gallery. No more complicated configuration, set-up or authentication of sensors. As simple as IoT should be!

In the B.One Gallery, you can directly view the measurement data, actions and histories of your IoT sensors. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers, for example, simply via a web link. The reports can be updated and the recipients only need a web browser. Simply let yourself and others be notified automatically if things are not as they should be so that you can act quickly. Find out more about the platform at: B.One Gallery

Do you already have B.One Gallery supported sensors that you want to visualise in the platform? Then you can of course integrate them yourself at any time.

Module 1: ZENNER IoT GatewayPLUS with LoRaWAN® network

When you purchase a ZENNER IoT GatewayPLUS Indoor, Outdoor or SMART, you will receive preconfigured access to the LoRaWAN® network EUROPE from ZC GmbH for 12 months and 50 devices to make your LoRaWAN® sensors known in the network and receive their data there. For INDOOR and OUTDOOR, data is transmitted via an integrated SIM card; for SMART, you need an available WLAN network with an Internet connection. You can find more information on the respective product pages of the devices.

Tip

ZENNER IoT GatewayPLUS SMART with LoRaWAN® network

Powerful Indoor GatewayPLUS SMART in the LoRaWAN® Network EUROPE of ZENNER Connect The ZENNER IoT GatewayPLUS SMART uses powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure connectivity of IoT sensors even under difficult environmental and installation conditions. This indoor gateway is ideally suited for receiving your LoRaWAN® devices and sensors inside a building and in the immediate vicinity, in order to receive the values of sometimes difficult-to-access sensors on several floors as well as basements, garages, gardens, car parks - all without additional repeaters. It can be used across all sectors for a wide range of IoT applications. The smart gateway ensures the LoRaWAN® reception of your LoRaWAN® end devices in the reception area of the gateway and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, of course, secure and AES 128 encrypted. The GatewayPLUS SMART gives you access to the ZENNER Connect LoRaWAN® network EUROPE. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client that you receive after ordering is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors). The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect LoRaWAN® network EUROPE, you only need to establish the power supply, connect the gateway to your WLAN and you can start immediately. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. Data transmission from your gateway to the backend system via your WLAN connection may incur additional costs. If you are planning a larger project, please contact us. We will be happy to provide you with individual support and advice. Scope of use ZENNER IoT GatewayPLUS SMART: With the ZENNER IoT GatewayPLUS SMART you receive LoRaWAN® connectivity and data transmission via your Wi-Fi in the ZENNER Connect LoRaWAN® network EUROPE for 12 months and use of up to 50 LoRaWAN® IoT sensors. The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider via your Wi-Fi! Of course, you only receive the data of your own end devices! Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. User Agreement ZENNER IoT GatewayPLUS SMART: Please note: This associated user agreement (also to be found below under "Available Downloads") is part of the contract when purchasing this gateway. LoRaWAN® network coverage ZENNER Connect: To the overview map of our network coverage: https://www.mz-connect.com/netzabdeckung/ NEW OPTIONAL: Order the B.One Gallery visualisation solution for 24 months and for 50 devices with ZENNER IoT PLUG&PLAY directly. In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be. User agreement for the visualisation solution B.One Gallery: => Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen. Exchange and inspiration in the B.One Community Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you! Join the B.One Community Features and functions of GatewayPLUS Smart Suitable for LoRaWAN® IoT solutions ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator. Gateway use ONLY in the following countries of the European Union:GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. Bidirectional LoRaWAN® radio communication Secure encrypted data transmission end-to-end (AES 128) No storage of sensor data such as meter reading values on the gateway LoRaWAN® gateway modules according to reference architecture 1.5 Connection to the backend with available WLAN network.Attention: The customer establishes the data transmission from the gateway to the backend via his own internet connection. This may incur additional costs for data transmission. Please note: The reception quality and range of your LoRaWAN® gateway depends on the installation location you have chosen. For details, please refer to the installation instructions or the User Guide. The average reception coverage inside a building can be up to 8-10 floors, depending on the building characteristics. The reception coverage outside the building where the gateway is mounted can be up to 1 kilometer. You will need WLAN connectivity at the gateway's mounting location. For operation you need a standard 230V power connection/socket. Declaration of Conformity (CE) and RoHS standards are complied with. Areas of application: Optimal for LoRaWAN® based IoT applications in buildings as well as in the building environment. Smart Building / Home / Office / School / Parking Indoor air quality measurement Submetering Technical data: Backhaul: Wi-Fi 802.11 b/g/n, frequency band: 2.4 GHz, security: WPA/WPA2 LoRa Channel: 8 channels, receive sensitivity: -140dBm, internal antenna TX power: up to +20dBm Frequency: EU-868 (862 - 870MHz) Power supply: 230V power outlet (Euro plug) / USB Type-C (900mA). Antennas: Internal - 1 x LoRa, 1 x Wi-Fi Protection class: IP40 Housing: Plastic with flame retardant according to UL94-2013 Rev.9-2019, class.: V-0 Dimensions [L x W x H]: 100 x 82 x 38 mm Weight: 160g Operating temperature: 0 °C to +40 °C Storage temperature: -40 °C to +70 °C LED: Wi-Fi status Preconfigured and connected to the ZENNER Connect LoRaWAN® network.(this is NOT changeable!) Mounting: power socket Standards: CE, RoHS

Manufacturer: ZENNER

€124.95*

ZENNER IoT GatewayPLUS Indoor with LoRaWAN® network

Powerful Indoor IoT GatewayPLUS in the LoRaWAN® Network EUROPE of ZENNER Connect GmbH The ZENNER IoT GatewayPLUS Indoor uses the powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure the connectivity of IoT sensors even under difficult environmental and installation conditions. The Indoor Gateway is ideal for receiving your LoRaWAN® devices and sensors inside a building and in the immediate vicinity, to receive the values of sometimes difficult-to-access sensors on several floors as well as basements, garages, gardens, car parks - all without additional repeaters. The device can be used across all sectors for a wide range of IoT applications. The ZENNER IoT GatewayPLUS Indoor has already been installed in over 30,000 LoRaWAN®system installations of the Minol ZENNER Group and is an integral part of many Minol ZENNER IoT system solutions. Due to its intentionally simple design, the gateway is hardly noticeable in its environment. The gateway ensures the LoRaWAN® reception of your LoRaWAN® end devices in the reception area of the gateway and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, this is of course secure and AES 128 encrypted. The GatewayPLUS INDOOR gives you access to the LoRaWAN® network EUROPE of ZENNER Connect. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client, which you receive after ordering, is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors). The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect EUROPE LoRaWAN® network, you only need to establish the power supply. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. The data transmission from your gateway to the backend system is carried out via the SIM card of ZENNER Connect included in the Gateway. If you are planning a larger project, please contact us. We will be happy to support and advise you individually. Scope of use ZENNER IoT GatewayPLUS Indoor: With the ZENNER IoT GatewayPLUS Indoor you receive LoRaWAN® connectivity and data transmission in the ZENNER Connect EUROPE LoRaWAN® network for 12 months and use of up to 50 LoRaWAN® IoT sensors. The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider. Of course, you only receive the data of your own end devices! Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. User Agreement ZENNER IoT GatewayPLUS Indoor: Please note: This associated user agreement (also to be found below under "Available Downloads") is part of the contract when purchasing this gateway. LoRaWAN® network coverage ZENNER Connect: To the overview map of our network coverage: To the network coverage NEW OPTIONAL: Order the B.One Gallery visualisation solution for 24 months and for 50 devices with ZENNER IoT PLUG&PLAY directly. In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be. User agreement for the visualisation solution B.One Gallery: => Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen. Exchange and inspiration in the B.One Community Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you! Join the B.One Community Features and functions of GatewayPLUS Indoor: Suitable for LoRaWAN® IoT solutions ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator. Gateway use ONLY in the following countries of the European Union:GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. Bidirectional LoRaWAN® radio communication Secure encrypted data transmission end-to-end (AES 128) No storage of sensor data such as meter readings on the gateway LoRaWAN®gateway modules according to reference architecture 1.5 Automatic switch from mobile radio (already included) to Ethernet backhaul possible. Attention: If the gateway is connected to a LAN connection, the customer establishes the data transmission from the gateway to the backend via his own Internet connection! This may incur additional costs for data transmission! Therefore, use the connection via the integrated mobile radio data card/SIM, which is already included. This way you will not incur any additional data transmission costs! Manufacturer's Declaration of Conformity including all applicable radio, low voltage and electricity regulations of Europe and RED (Radio Equipment Directive). Please note: The reception quality and range of your LoRaWAN®gateway depends on the mounting or installation location you choose. For details, please refer to the installation instructions and the additional technical documentation. The average reception area inside a building can cover up to 8-10 floors, depending on the nature of the building. The reception coverage outside the building in which the gateway is installed can be up to 1 kilometre. You need mobile radio coverage at the installation or mounting location of the gateway! Alternatively, a separate Ethernet connection. For operation, you need a standard 230V power connection/socket. Areas of application: Optimal for LoRaWAN® based IoT applications in buildings as well as in the building environment. Smart Building / Home / Office / School / Parking Smart City / Smart Industry Indoor air quality measurement Technical data: Cellular: Mini SIM - 2G, 3G (UMTS), 4G (LTE) - internal antenna Ethernet RJ45 - priority over cellular. Ethernet: RJ45 - priority over mobile radio LoRa channel: 8 channels - internal antenna(s) TX power: max. 27 dBm (500 mW) conducted Frequency: EU-868 MHz Power supply: External power supply (230V) included. Antennas: Internal - 1 x LoRa, 1 x mobile radio Protection class: IP30 Housing: Plastic with flame protection according to UL94-2013 Rev.9-2019, class.:V0 Dimensions [L x W x H]: 18.4 x 12.7 x 4.8 cm Operating temperature: 0°C to +50°C Storage temperature: -40°C to +80°C LED: Power, LAN, mobile radio, Preconfigured and connected to the ZENNER Connect LoRaWAN® network (this is NOT changeable!) Mounting: Wall (bracket incl. screws and dowels included) Maintenance: Remote firmware upgrades are automatic. Certification: EN 301 489-3, EN 300 220-2

Manufacturer: ZENNER

€369.00*

ZENNER IoT GatewayPLUS Outdoor with LoRaWAN® network

Powerful Outdoor IoT GatewayPLUS in the LoRaWAN® Network EUROPE of ZENNER Connect GmbH The ZENNER IoT GatewayPLUS Outdoor for building LoRaWAN coverage and realising IoT use cases. The ZENNER IoT GatewayPLUS Outdoor uses the powerful LoRaWAN technology, whose excellent building penetration and wide-area network coverage ensure the connectivity of IoT sensors even under difficult environmental and installation conditions. The outdoor gateway is ideal for LoRaWAN network coverage in rural and urban areas to receive readings from multiple sensors. The device can be used across divisions for a wide range of IoT applications and is an integral part of the ZENNER IoT system solutions. With just a few gateways, entire cities can be covered. Thanks to the very robust housing made of painted aluminium, the outdoor gateway is very resilient to extreme weather conditions and is characterised by a high level of fail-safety. In addition to the two external LoRa antennas for the 16 Channels, the ZENNER IoT GatewayPLUS Outdoor also uses an external LTE antenna to ensure the best possible connection to the backend - provided there is no Ethernet connection. This feature is not found in comparable competitor products. The gateway ensures LoRaWAN reception of your LoRaWAN end devices in the gateway's reception area and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN network EUROPE. Like all data transmissions, this is of course secure and AES 128 encrypted. The GatewayPLUS OUTDOOR gives you access to the LoRaWAN® network EUROPE of ZENNER Connect. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client, which you receive after ordering, is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors). The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect EUROPE LoRaWAN® network, you only need to establish the power supply. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. The data transmission from your gateway to the backend system is carried out via the SIM card of ZENNER Connect included in the Gateway. If you are planning a larger project, please contact us. We will be happy to support and advise you individually. By the way: ZENNER includes everything you need to operate the gateway in the scope of delivery - from the mounting device to all antennas and cables. Scope of use ZENNER IoT GatewayPLUS Outdoor: With the ZENNER IoT GatewayPLUS Outdoor you receive LoRaWAN connectivity and data transmission in the ZENNER Connect network EUROPE for 12 months and use of up to 50 LoRaWAN IoT sensors. The gateway is part of the LoRaWAN network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider. Of course, you only receive the data of your own end devices! Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. Associated User Agreement ZENNER IoT GatewayPLUS Outdoor: Please note: This corresponding associated user agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway. LoRaWAN® network coverage ZENNER Connect: To the overview map of our network coverage: To the network coverage NEW OPTIONAL: Order the B.One Gallery visualisation solution for 24 months and for 50 devices with ZENNER IoT PLUG&PLAY directly. In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be. User agreement for the visualisation solution B.One Gallery: => Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen. Exchange and inspiration in the B.One Community Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you! Join the B.One Community Features and functions of the GatewyPLUS Outdoor: Suitable for LoRaWAN IoT solutions ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator. Gateway use ONLY in the following countries of the European Union: GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA. Bidirectional LoRaWAN radio communication Secure encrypted data transmission end-to-end (AES 128) No storage of sensor data such as meter readings on the gateway LoRaWAN gateway modules according to reference architecture 1.5 Automatic switch from mobile radio (already included) to Ethernet backhaul possible, Attention! If the gateway is connected to an Ethernet connection, the customer establishes the data transmission from the gateway to the backend via his own Internet connection! This may incur additional costs for the data transmission! Therefore, use the connection via the integrated mobile radio data card/SIM, which is already included. This way you will not incur any additional data transmission costs! Manufacturer's Declaration of Conformity including all applicable radio, low voltage and electricity regulations of Europe and RED (Radio Equipment Directive). Please note: The reception quality and range of your LoRaWAN gateway depends on the mounting or installation location you choose. For details, please refer to the installation instructions and the additional technical documentation. You need mobile radio coverage at the installation or mounting location of the gateway! Alternatively, a separate Ethernet connection. For operation, you need a standard 230V power connection/socket! Plug & Play - easy integration through pre-configured software Security patches and software updates are distributed automatically LoRaWAN gateway modules according to reference architecture 1.5 Automatic switch from mobile radio to Ethernet backhaul (if available) Manufacturer's Declaration of Conformity including all applicable radio, low voltage and electricity regulations of Europe and RED (Radio Equipment Directive) Application areas: Optimal for outdoor IoT use cases Smart City, Smart Parking, Smart Waste, Smart Lighting, ... e.g. monitoring of local network transformer stations; shaft meter reading Smart Industry, Retail, Logistics, SMB, Smart Agriculture & Farming, Asset Tracking... Scope of delivery: IoT Outdoor GatewayPLUS 2x LoRa antenna incl. antenna cable 1x LTE antenna incl. antenna cable 1x Ethernet cable (5m) Mounting device incl. pole mount PoE injector Potential equalisation cable (earthing cable) Cable tie Technical data: Mobile radio: Mini SIM - 2G, 3G (UMTS), 4G (LTE) - external LTE antenna Ethernet: RJ45 - priority over mobile radio LoRa channel: 16 channels - two external antennas TX power: max. 27 dBm (500 mW) conducted Frequency: EU-868 Power supply: Power over Ethernet (PoE) Antennas: External: 2 x LoRa, 1 x LTE (antennas incl. holder included in delivery) Protection class: IP67 Housing: Aluminium, lacquered Operating temperature: 0°C to +50°C Storage temperature: -40°C to +80°C Mounting: Wall, pole (bracket incl. earth cable included, galvanised steel) Maintenance: Remote firmware upgrades via ZENNER Cloud Certification: EN 301 489-3, EN 300 220-2

Manufacturer: ZENNER

€989.00*

Module 2: Visualisation platform B.One Gallery

Would you like to receive B.One Gallery access and view your sensor data visually on the visualisation platform? Then simply order the B.One Gallery as well. When you purchase the "B.One Gallery" item, you receive access for 24 months and can link up to 50 sensors. You can find more information about the B.One Gallery here.

Access to the B.One Gallery for 24 months and up to 50 devices

B.One Gallery - The standardised visualisation platform for your IoT sensors & solutions With the purchase of this service product, you receive an account on the B.One Gallery visualisation platform with access for up to 50 devices for a term of 24 months. The contractual basis is the associated user agreement. It is an integral part of the contract when this service is purchased. The period of use begins on the date of purchase, i.e. date of purchase = date of performance. With the B.One Gallery you can display sensor data in near real-time and in different formats. Standardised representations enable intuitive and very simple operation. Create dashboards, reports and notification settings for your IoT use cases with just a few clicks, practically without prior knowledge. Keep an eye on and access your data at any time and from anywhere. The B.One Gallery as a visualisation platform for IoT applications is browser-based and can be displayed on all modern browsers. Forget about installations, updates, drivers & Co. Use your B.One Gallery from your smartphone, tablet or PC, see your measurement data, actions and histories of your IoT sensors everywhere and stay informed. Create your own graphics, charts and reports with just a few clicks and share them with your colleagues, partners, customers or service providers simply via LInk. The great thing about this is that the recipients can simply use them without being users of the B.One Gallery themselves. You decide whether the reports are static or update automatically. No matter how many IoT devices, application scenarios or locations you want to manage and monitor, you only need one B.One Gallery - it is compatible and simply grows with you. From a single sensor in your office, workshop, warehouse, cold room, production hall, restaurant, shop, farm, administration building and and.... to fully automated IoT tracking of numerous and diverse use cases, no matter whether indoor or outdoor, no matter how many locations in your company, your buildings, on the company premises or from the entire smart city or region. Stay informed at all times and up to date! The integrated monitoring and notification system detects deviating states and informs you immediately via the notification channels you set when things are no longer as they should be. With the easy-to-use yet sophisticated user and authorisation system, you can create additional users in no time at all, grant approvals and also compare your own IoT systems with others - for example, your consumption values, temperatures, etc. B.ONE GALLERY is the basis for your IoT solutions, sensor visualisation, dashboards and reporting, easy setup of alarms when things are not as they should be. The possible uses and visualisation of IoT use cases are almost unlimited. More than 100 sensors are currently supported for a wide variety of use cases, and more are being added all the time. No matter whether you want to monitor climate data - indoor or outdoor - or air quality, room temperature, humidity, CO2, cooling, soil moisture, precipitation amounts, energy consumption (water, heat, electricity,...), movement, presence, brightness, location and position, system statuses, opening and closing status of windows, doors, gates,... Filling quantities whether for tanks, containers, boxes, silos, waste bins,... the B.One Gallery is the visualisation solution that shows you all this in a simple and uncomplicated way. Furthermore, it doesn't matter in which sector you are active, whether in trade, trade or industry, whether you are a company, a municipality, a city or a public authority. The B.One Gallery shows you your IoT applications and sensor data, simply and easily understandable. The way IoT should be.

Manufacturer: ZENNER

€110.00*

Module 3: Add your sensors to the ZC network and your B.One Gallery

To complete your use case, you will of course need one or more sensors. After purchase, you have the option of manually adding your sensors to the ZENNER Connect LoRaWAN® network EUROPE and/or your B.One Gallery yourself.

Tip

ZENNER CO2 INDICATOR L868 ID A for LoRaWAN®

ZENNER CO2 INDICATOR L868 ID A for LoRaWAN® The ZENNER CO2 INDICATOR is a compact indoor LoRaWAN® radio sensor (868MHz) for measuring the CO2 content of indoor air. This product uses the photoacoustic principle to detect the CO2 concentration (ppm) in real time, enabling more efficient ventilation behaviour and faster response time. With the integrated display and the colour-changing LED display, the sensor always provides real-time information about the current CO2 value, the battery level and the status of the LoRaWAN® connection. An optimal stationary and mobile companion in the company, at the workplace, in the meeting room at a meeting or in the canteen. It can be placed on any flat surface. In addition, the device can also be used "stand alone", i.e. without a LoRaWAN® connection, e.g. at a meeting outside the company, when visiting a customer or a restaurant outside the range of the LoRaWAN® network. Without LoRaWAN® connection, however, no remote monitoring or alarming can take place. The CO2 limits can be set individually by radio command (downlink). The device can be operated with the integrated rechargeable battery or permanently powered by a standard USB-A power supply unit 5V. Please note that only the USB-A to USB-C charging cable is included, a power supply unit is also required. OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services: Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased ZENNER CO2 Indicator is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses. Order, plug in, switch on and view the ZENNER CO2 Indicator data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser NOW NEW also available and expandable within the Actillity ZENNER DataCake Starterkit on ThingPARK. Download CO2 Sensor Actility ZENNER Datacake Bundle Link to ThingPARK Actility ZENNER DataCake AirQuality Solution Use Cases Indoor Air Quality Smart Building Smart School Smart Office Smart Home Product Features Modern design Display with CO2 indication (ppm) as well as quality of LoRaWAN connection and battery status LED traffic light Integrated battery Configuration Over the Air (OTA) Evaluation of the CO2 measured values Range (ex works) Evaluation LED Farbe < 800ppm normal green 800 – 999ppm slightly increased yellow 1.000 – 1.399ppm high purple > 1.399ppm very high red The measuring ranges can be set individually via LoRaWAN® downlink. Specifications Model CO2 INDICATOR L868 ID A Weight 115g Size 63,6 x 46,0 x 54,6mm Display Size 59,9 x 49,9mm LoRaWAN® Klasse A Frequency 863 ~ 870MHz Transmit Power max. 14dBm Battery 2.000mAh Power Input 5V⎓ 1A (Hinweis: im Lieferumfang ist kein Netzteil enthalten) Operating Temperature 0 ~ 40℃ Operating Humidity 0 ~ 99%rH (nicht kondensierende Umgebung) CO2 Measuring Range 400 ~ 9.999ppm Accuracy of 400 ~ 2.000ppm --> ±50ppm Accuracy of 2.000 ~ 9.999ppm --> no guarantee Scope of Delivery ZENNER CO2 Indicator L868 ID A for LoRaWAN User Manual USB-A to USB-C Cabel Notice: There is no 5V power supply included in the delivery. You can use a commercially available smartphone USB-A power adapter, for this purpose.

Manufacturer: ZENNER

€52.90* €99.90* (47.05% saved)

ELSYS ERS CO2 Lite wireless multi-room sensor for air quality measurement

LoRaWAN CO2 Sensor from ELSYS for indoor climate monitoring A LoRaWAN room sensor to measure the indoor climate (CO2, temperature, humidity) in an inconspicuous housing for easy wall mounting. Compared to the ERS CO2 sensor, the ELSYS ERS CO2 Lite does not need to detect brightness and movement and is therefore the ideal sensor for measuring the indoor climate.

Manufacturer: ELSYS

€139.00* €169.00* (17.75% saved)
previously €169.00*

DEOS SAM CO2 Air Quality LoRaWAN®

DEOS SAM CO2 Air Quality LoRaWAN® The DEOS SAM CO2 room air sensor from DEOS AG measures the temperature, humidity and CO2 content in indoor rooms. By means of a visual and acoustic alarm when the adjustable CO2 threshold values are exceeded, you always keep an eye on the indoor air quality and can ventilate as required. The number and colours of the LEDs change depending on the CO2 content (ppm). The data is transmitted to the corresponding backend via LoRaWAN®. An external power supply is provided via a mini-USB connection - the cable and the power supply unit are included in the scope of delivery. Areas of application Schools, workplaces Offices, event rooms Smart buildings Warning function Visual and audible alarm when CO2 limits are exceeded (limits can be set individually) Optical temperature display by LEDs

Manufacturer: DEOS AG

€289.00* €299.00* (3.34% saved)

You want to monitor more than temperature and humidity, go ahead, you can easily add all IoT PLUG&PLAY sensors to your IoT PLUG&PLAY solution. Whether door sensors, motion, lighting, leaks, smoke alarm status... Simply expand your solution.
