ZENNER IoT PLUG&PLAY Level monitoring
With the new simple ZENNER IoT PLUG&PLAY convenience solution, you can ensure optimal monitoring of fill levels for IoT-supported detection of liquid or solid goods. Start monitoring the fill level e.g. at silos, oil tanks, waste or industrial containers to optimise supply and disposal processes or to monitor production processes and merchandise management. The sensor technology portfolio includes various technical detection approaches (ultrasonic, optical, etc.) as well as different sensor sizes with variable installation options. Filling level sensors that provide additional information, such as geodata, ambient conditions or movement, can be used to suit your application.
All ZENNER IoT PLUG&PLAY solutions are already fully developed and are already integrated in the B.One Gallery. Just select all the necessary components for your use cases. The great thing about it is that all IoT PLUG&PLAY sensors, regardless of the use case, can be combined with each other and are displayed directly in the B.One Gallery as soon as the sensor data are received. For all applications, even in combination, normally only 1 GatewayPLUS (per building) and only once the B.One Gallery is needed. Order, unpack, plug in, run! That is ZENNER IoT PLUG&PLAY. IoT is that simple and modular.
With ZENNER IoT PLUG&PLAY, you save the costs of time-consuming retrofitting of building cabling and expensive conversions. The sensors transmit via LoRaWAN® radio through ceilings and walls and deliver the measurement data to your B.One Gallery.
As with all ZENNER IoT PLUG&PLAY solutions, you can add your sensors purchased in our shop manually by yourself into your LoRaWAN network EUROPE of ZENNER Connect (ZC) GmbH and your B.One Gallery. There you can easily manage and visualise your LoRaWAN® sensors.
Visualisation of sensor data within B.One Gallery
Order, plug in, switch on and visit your B.One Gallery. No more cumbersome configuring, setting up, authenticating sensors. As simple as IoT should be!
In the B.One Gallery you can directly view the measurement data, actions and histories of your IoT sensors. Design and view your graphs, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers, for example, simply via a web link. The reports can be updated and the recipients only need a web browser. Let yourself and others be automatically notified if things are not as they should be in order to be able to act quickly. Now you can also easily view your reports and dashboards directly on your smartphone...
You already have B.One Gallery supported sensors that should be visualised in the platform? Then you can of course integrate them yourself at any time.
Module 1: ZENNER IoT GatewayPLUS with LoRaWAN® network
When purchasing a ZENNER IoT GatewayPLUS Indoor, Outdoor or SMART, you will receive a pre-configured access to the LoRaWAN® network EUROPE of ZC GmbH for 12 months and 50 devices to make your LoRaWAN® sensors known in the network and to receive their data there. With INDOOR and OUTDOOR, data transmission takes place via an integrated SIM card, with SMART you need an available WLAN network with Internet connection. You can find more information on the respective product pages of the devices.
Tip
ZENNER IoT GatewayPLUS SMART with LoRaWAN® network
€124.95*
Powerful Indoor GatewayPLUS SMART in the LoRaWAN® Network EUROPE of ZENNER Connect
The ZENNER IoT GatewayPLUS SMART uses powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure connectivity of IoT sensors even under difficult environmental and installation conditions.
This indoor gateway is ideally suited for receiving your LoRaWAN® devices and sensors inside a building and in the immediate vicinity, in order to receive the values of sometimes difficult-to-access sensors on several floors as well as basements, garages, gardens, car parks - all without additional repeaters. It can be used across all sectors for a wide range of IoT applications.
The smart gateway ensures the LoRaWAN® reception of your LoRaWAN® end devices in the reception area of the gateway and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, of course, secure and AES 128 encrypted.
The GatewayPLUS SMART gives you access to the ZENNER Connect LoRaWAN® network EUROPE. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client that you receive after ordering is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors).
The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect LoRaWAN® network EUROPE, you only need to establish the power supply, connect the gateway to your WLAN and you can start immediately. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. Data transmission from your gateway to the backend system via your WLAN connection may incur additional costs. If you are planning a larger project, please contact us. We will be happy to provide you with individual support and advice.
Scope of use ZENNER IoT GatewayPLUS SMART:
With the ZENNER IoT GatewayPLUS SMART you receive LoRaWAN® connectivity and data transmission via your Wi-Fi in the ZENNER Connect LoRaWAN® network EUROPE for 12 months and use of up to 50 LoRaWAN® IoT sensors.
The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider via your Wi-Fi! Of course, you only receive the data of your own end devices!
Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.
User Agreement ZENNER IoT GatewayPLUS SMART:
Please note: This associated user agreement (also to be found below under "Available Downloads") is part of the contract when purchasing this gateway.
LoRaWAN® network coverage ZENNER Connect:
To the overview map of our network coverage: https://www.mz-connect.com/netzabdeckung/
NEW OPTIONAL: Order the B.One Gallery visualisation solution for 24 months and for 50 devices with ZENNER IoT PLUG&PLAY directly.
In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be.
User agreement for the visualisation solution B.One Gallery:
=> Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen.
Exchange and inspiration in the B.One Community
Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you!
Join the B.One Community
Features and functions of GatewayPLUS Smart
Suitable for LoRaWAN® IoT solutions
ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator.
Gateway use ONLY in the following countries of the European Union:GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.
Bidirectional LoRaWAN® radio communication
Secure encrypted data transmission end-to-end (AES 128)
No storage of sensor data such as meter reading values on the gateway
LoRaWAN® gateway modules according to reference architecture 1.5
Connection to the backend with available WLAN network.Attention: The customer establishes the data transmission from the gateway to the backend via his own internet connection. This may incur additional costs for data transmission.
Please note: The reception quality and range of your LoRaWAN® gateway depends on the installation location you have chosen. For details, please refer to the installation instructions or the User Guide.
The average reception coverage inside a building can be up to 8-10 floors, depending on the building characteristics.
The reception coverage outside the building where the gateway is mounted can be up to 1 kilometer.
You will need WLAN connectivity at the gateway's mounting location. For operation you need a standard 230V power connection/socket.
Declaration of Conformity (CE) and RoHS standards are complied with.
Areas of application:
Optimal for LoRaWAN® based IoT applications in buildings as well as in the building environment.
Smart Building / Home / Office / School / Parking
Indoor air quality measurement
Submetering
Technical data:
Backhaul: Wi-Fi 802.11 b/g/n, frequency band: 2.4 GHz, security: WPA/WPA2
LoRa Channel: 8 channels, receive sensitivity: -140dBm, internal antenna
TX power: up to +20dBm
Frequency: EU-868 (862 - 870MHz)
Power supply: 230V power outlet (Euro plug) / USB Type-C (900mA).
Antennas: Internal - 1 x LoRa, 1 x Wi-Fi
Protection class: IP40
Housing: Plastic with flame retardant according to UL94-2013 Rev.9-2019, class.: V-0
Dimensions [L x W x H]: 100 x 82 x 38 mm
Weight: 160g
Operating temperature: 0 °C to +40 °C
Storage temperature: -40 °C to +70 °C
LED: Wi-Fi status
Preconfigured and connected to the ZENNER Connect LoRaWAN® network.(this is NOT changeable!)
Mounting: power socket
Standards: CE, RoHS
Manufacturer:
ZENNER
ZENNER IoT GatewayPLUS Indoor with LoRaWAN® network
€369.00*
Powerful Indoor IoT GatewayPLUS in the LoRaWAN® Network EUROPE of ZENNER Connect GmbH
The ZENNER IoT GatewayPLUS Indoor uses the powerful LoRaWAN® technology, whose excellent building penetration and wide-area network coverage ensure the connectivity of IoT sensors even under difficult environmental and installation conditions.
The Indoor Gateway is ideal for receiving your LoRaWAN® devices and sensors inside a building and in the immediate vicinity, to receive the values of sometimes difficult-to-access sensors on several floors as well as basements, garages, gardens, car parks - all without additional repeaters. The device can be used across all sectors for a wide range of IoT applications.
The ZENNER IoT GatewayPLUS Indoor has already been installed in over 30,000 LoRaWAN®system installations of the Minol ZENNER Group and is an integral part of many Minol ZENNER IoT system solutions. Due to its intentionally simple design, the gateway is hardly noticeable in its environment.
The gateway ensures the LoRaWAN® reception of your LoRaWAN® end devices in the reception area of the gateway and transmits their data to the backend. In addition to the reception of your devices beyond your own gateway, you also receive their data as a special added value if they are received by one of the other gateways in the ZENNER Connect LoRaWAN® network EUROPE. Like all data transmissions, this is of course secure and AES 128 encrypted.
The GatewayPLUS INDOOR gives you access to the LoRaWAN® network EUROPE of ZENNER Connect. In order to automatically establish a network connection after commissioning, the gateway has already been stored for you in the backend system ZENNER Datahub. You therefore do not have to integrate the gateway into the system yourself. The access to your personal ZENNER Datahub account/client, which you receive after ordering, is ultimately only required for the installation of sensors whose data you want to receive via the gateway. Unless: You order your sensors with the practical ZENNER IoT PLUG&PLAY booking-in service (more on this below or on the product pages of the respective sensors).
The gateway is therefore already completely and permanently pre-configured and an integral part of the ZENNER Connect EUROPE LoRaWAN® network, you only need to establish the power supply. With the gateway, the LoRaWAN® data transmission of 50 own LoRaWAN end devices is included in the purchase price for 12 months. The data transmission from your gateway to the backend system is carried out via the SIM card of ZENNER Connect included in the Gateway. If you are planning a larger project, please contact us. We will be happy to support and advise you individually.
Scope of use ZENNER IoT GatewayPLUS Indoor:
With the ZENNER IoT GatewayPLUS Indoor you receive LoRaWAN® connectivity and data transmission in the ZENNER Connect EUROPE LoRaWAN® network for 12 months and use of up to 50 LoRaWAN® IoT sensors. The gateway is part of the LoRaWAN® network of ZENNER Connect GmbH (ZC). Due to the technology, all LoRaWAN® end devices in the reception range of your gateway are received in encrypted form and transmitted to the network provider. Of course, you only receive the data of your own end devices!
Due to network regulation, the gateway is to be used within the European Union and currently ONLY in the following COUNTRIES! GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.
User Agreement ZENNER IoT GatewayPLUS Indoor:
Please note: This associated user agreement (also to be found below under "Available Downloads") is part of the contract when purchasing this gateway.
LoRaWAN® network coverage ZENNER Connect:
To the overview map of our network coverage: To the network coverage
NEW OPTIONAL: Order the B.One Gallery visualisation solution for 24 months and for 50 devices with ZENNER IoT PLUG&PLAY directly.
In addition, you secure the possibility that your purchased sensors can be automatically created in the ZC LoRaWAN network and already added to your B.One Gallery with the ZENNER IoT PLUG&PLAY login service. No more cumbersome configuration, setup, authentication of sensors necessary in the visualisation. As simple as IoT should be.
User agreement for the visualisation solution B.One Gallery:
=> Please note when choosing the ZENNER IoT PLUG&PLAY OPTION! that this associated User Agreement (also available below under "Available downloads") is part of the contract when purchasing this gateway with the ZENNER IoT PLUG&PLAY OPTION choosen.
Exchange and inspiration in the B.One Community
Have you already implemented your own LoRaWAN® use cases in the Internet of Things or are you new to the topic and would like to exchange ideas? Or has your boss given you the task of diving into the Internet of Things? Then the new B.One Community is the right place for you!
Join the B.One Community
Features and functions of GatewayPLUS Indoor:
Suitable for LoRaWAN® IoT solutions
ZENNER Connect GmbH is the LoRaWAN® network operator of your gateway. This means that you do not need to register as an independent LoRaWAN® network operator.
Gateway use ONLY in the following countries of the European Union:GERMANY, AUSTRIA, DENMARK, SWEDEN, POLAND, NETHERLANDS, FRANCE, SPAIN, ITALY, CROATIA and SLOVENIA.
Bidirectional LoRaWAN® radio communication
Secure encrypted data transmission end-to-end (AES 128)
No storage of sensor data such as meter readings on the gateway
LoRaWAN®gateway modules according to reference architecture 1.5 Automatic switch from mobile radio (already included) to Ethernet backhaul possible.
Attention: If the gateway is connected to a LAN connection, the customer establishes the data transmission from the gateway to the backend via his own Internet connection! This may incur additional costs for data transmission! Therefore, use the connection via the integrated mobile radio data card/SIM, which is already included. This way you will not incur any additional data transmission costs!
Manufacturer's Declaration of Conformity including all applicable radio, low voltage and electricity regulations of Europe and RED (Radio Equipment Directive).
Please note: The reception quality and range of your LoRaWAN®gateway depends on the mounting or installation location you choose. For details, please refer to the installation instructions and the additional technical documentation.
The average reception area inside a building can cover up to 8-10 floors, depending on the nature of the building.
The reception coverage outside the building in which the gateway is installed can be up to 1 kilometre.
You need mobile radio coverage at the installation or mounting location of the gateway! Alternatively, a separate Ethernet connection. For operation, you need a standard 230V power connection/socket.
Areas of application:
Optimal for LoRaWAN® based IoT applications in buildings as well as in the building environment.
Smart Building / Home / Office / School / Parking
Smart City / Smart Industry
Indoor air quality measurement
Technical data:
Cellular: Mini SIM - 2G, 3G (UMTS), 4G (LTE) - internal antenna Ethernet RJ45 - priority over cellular.
Ethernet: RJ45 - priority over mobile radio
LoRa channel: 8 channels - internal antenna(s)
TX power: max. 27 dBm (500 mW) conducted
Frequency: EU-868 MHz
Power supply: External power supply (230V) included.
Antennas: Internal - 1 x LoRa, 1 x mobile radio
Protection class: IP30
Housing: Plastic with flame protection according to UL94-2013 Rev.9-2019, class.:V0
Dimensions [L x W x H]: 18.4 x 12.7 x 4.8 cm
Operating temperature: 0°C to +50°C
Storage temperature: -40°C to +80°C
LED: Power, LAN, mobile radio,
Preconfigured and connected to the ZENNER Connect LoRaWAN® network (this is NOT changeable!)
Mounting: Wall (bracket incl. screws and dowels included)
Maintenance: Remote firmware upgrades are automatic.
Certification: EN 301 489-3, EN 300 220-2
Manufacturer:
ZENNER
Module 2: Visualisation platform B.One Gallery
You would like to receive a B.One Gallery access and thus view your sensor data optically prepared on the visualisation platform? Then simply order the B.One Gallery as well. With the purchase of the article "B.One Gallery" you receive access for 24 months and can link up to 50 sensors. You can find more information about the B.One Gallery here.
Access to the B.One Gallery for 24 months and up to 50 devices
€110.00*
B.One Gallery - The standardised visualisation platform for your IoT sensors & solutions
With the purchase of this service product, you receive an account on the B.One Gallery visualisation platform with access for up to 50 devices for a term of 24 months.
The contractual basis is the associated user agreement. It is an integral part of the contract when this service is purchased. The period of use begins on the date of purchase, i.e. date of purchase = date of performance.
With the B.One Gallery you can display sensor data in near real-time and in different formats. Standardised representations enable intuitive and very simple operation. Create dashboards, reports and notification settings for your IoT use cases with just a few clicks, practically without prior knowledge.
Keep an eye on and access your data at any time and from anywhere.
The B.One Gallery as a visualisation platform for IoT applications is browser-based and can be displayed on all modern browsers. Forget about installations, updates, drivers & Co. Use your B.One Gallery from your smartphone, tablet or PC, see your measurement data, actions and histories of your IoT sensors everywhere and stay informed. Create your own graphics, charts and reports with just a few clicks and share them with your colleagues, partners, customers or service providers simply via LInk. The great thing about this is that the recipients can simply use them without being users of the B.One Gallery themselves. You decide whether the reports are static or update automatically.
No matter how many IoT devices, application scenarios or locations you want to manage and monitor, you only need one B.One Gallery - it is compatible and simply grows with you. From a single sensor in your office, workshop, warehouse, cold room, production hall, restaurant, shop, farm, administration building and and.... to fully automated IoT tracking of numerous and diverse use cases, no matter whether indoor or outdoor, no matter how many locations in your company, your buildings, on the company premises or from the entire smart city or region.
Stay informed at all times and up to date!
The integrated monitoring and notification system detects deviating states and informs you immediately via the notification channels you set when things are no longer as they should be. With the easy-to-use yet sophisticated user and authorisation system, you can create additional users in no time at all, grant approvals and also compare your own IoT systems with others - for example, your consumption values, temperatures, etc.
B.ONE GALLERY is the basis for your IoT solutions, sensor visualisation, dashboards and reporting, easy setup of alarms when things are not as they should be.
The possible uses and visualisation of IoT use cases are almost unlimited.
More than 100 sensors are currently supported for a wide variety of use cases, and more are being added all the time.
No matter whether you want to monitor climate data - indoor or outdoor - or air quality, room temperature, humidity, CO2, cooling, soil moisture, precipitation amounts, energy consumption (water, heat, electricity,...), movement, presence, brightness, location and position, system statuses, opening and closing status of windows, doors, gates,... Filling quantities whether for tanks, containers, boxes, silos, waste bins,... the B.One Gallery is the visualisation solution that shows you all this in a simple and uncomplicated way. Furthermore, it doesn't matter in which sector you are active, whether in trade, trade or industry, whether you are a company, a municipality, a city or a public authority. The B.One Gallery shows you your IoT applications and sensor data, simply and easily understandable. The way IoT should be.
Manufacturer:
ZENNER
Module 3: Add your sensors to the ZC network and your B.One Gallery
To complete your use case, you will of course need one or more sensors.
After purchase, you have the option of manually adding your sensors to the ZENNER Connect LoRaWAN® network EUROPE and/or your B.One Gallery yourself.
Tip
WILSEN wireless ultrasonic sensor WS-UCC4000
€392.90*
Wireless ultrasonic sensor with LoRaWAN® interface WS-UCC4000
The wireless ultrasonic sensor can be used for remote monitoring of fill level.The fill level, but also other parameters such as geo data and sensor status data, are measured or recorded in configurable time intervals andtransmitted to a counterpart in the LoRa network from where they are available for pure display or further processing.The sensor is parameterised via a Bluetooth interface using a mobile device (smartphone or tablet) and the WILSEN app belonging to the sensor.
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased WILSEN wireless ultrasonic sensor is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Battery powered
Data transmission via LoRaWAN
LoRaWAN downlink channel for querying and adjusting parameter values
Bluetooth interface for commissioning, parameterization and diagnostics
Manufacturer:
Pepperl+Fuchs
Tekelek TEK766 Ultrasonic Level Sensor LoRaWAN
€143.90*
Ultrasonic LoRaWAN Sensor Tek766 for tank level monitoring.
The LoRaWAN-based Tek766 is a battery powered, configurable ultrasonic level sensor with integrated wireless interface.
Use cases:
Monitoring of fill levels in tanks
Monitoring of fluid levels
Ensuring the continuous availability of fuels or other operating resources
Monitorable liquids:
Fuels
Heating oil
Kerosene
Water
Waste oil
and more
Benefits:
Accurate and reliable monitoring of tank levels
Alert when filling levels are below or exceeded
Optimization of procurement and delivery
Optimizing your logistics
Increase in process efficiency
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased Tekelek TEK766 Ultrasonic Level Sensor is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Technical characteristics:
Remote configuration
Easy installation
Up to 14 years of battery life
LoRaWAN radio interface (868 MHz)
Up to 15 km range
CE conformity and ROHS conformity
Manufacturer:
Tekelek
You want to monitor more than temperature and humidity, go ahead, all IoT PLUG&PLAY sensors can be easily added to your IoT PLUG&PLAY solution. Whether it's door sensors, motion, lighting, leakage, smoke detector status... Just expand your solution.
EXPAND your Solution
%
SENSATIVE Strips Multisensor +Guard for LoRaWAN®
€59.90*
€99.95*
(40.07% saved)
SENSATIVE Strips Multisensor MS +Guard for LoRaWAN®
The Strips Multisensor +Guard from SENSATIVE has several promising applications and is the ideal choice for a professional indoor IoT application. Due to its ultra-slim shape, the sensor can be mounted almost anywhere.The minimalistic design as well as the easy mounting and long battery life, make the Strips the go-to sensor for architects and design-conscious users.
The magnetic contact sensor is activated ex works, which can monitor, detect and alarm the opening and closing of doors, windows, drawers, etc. In addition a temperature and brightness sensor can be activated. The data and measured values are transmitted to the corresponding backend via LoRaWAN®.
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased SENSATIVE Strips Multisensor+Guard is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Areas of application:
Smart Home
Smart Office
Smart School
Smart Building
Performance features:
Model: Strips MS +Guard
Measurement parameters:
Magnetic sensor (door and window)
Configurable: Temperature: +/- 0.24°C, Ambient light: 1-64000 LUX
Dimensons:
Sensor: 195mm x 15mm x 3mm
Magnet: 30mm x 11mm x 1mm
Operating conditions: -30°C to +60°C
Application area: Indoor and Outdoor
LoRaWAN® device class: Class A
Activation: OTAA
Configuration: Downlink
Frequency: Europe (863-870 MHz)
Transmit power: +14dBm
Transmission interval: configurable
Power supply: built-in LiMnO2 battery
Battery replaceable: no
Battery life: up to 10 years (Battery Calculator)
Accessories: +Switch, +Clip
Manufacturer:
Sensative
Sensoneo Smart Waste Ultrasonic Sensor LoRaWAN Single 3.0
€228.90*
Sensoneo Smart Waste level sensor Single 3.0 for monitoring the amount of waste.
The Sensoneo Single Sensor LoRaWAN is an enterprise-class sensor. Designed for various types of containers from high capacity to small containers, it meets the needs of the customers wanting the secure data transfer to cloud-based applications.
The ultrasonic sensors is able to monitor any type of waste in bins of various type and size. It is very robust, water and shock resistant and can be connected to any LoRaWAN.
Get real-time data on fill-level in bins.
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased Sensoneo Smart Waste Ultrasonic Sensor is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Manufacturer:
Sensoneo
Decentlab Ultrasonic Sensor for Distance & Level DL-MBX-001 LoRaWAN®
€790.90*
Ultrasonic Sensor for Distance & Level DL-MBX-001 LoRaWAN®
The Decentlab ultrasonic sensor DL-MBX-001 is suitable for outdoor use and enables remote monitoring of water levels in open waters, tank levels, groundwater levels and various applications.
It measures the distance between the sensor head and the target. The measuring principle is based on ultrasonic waves that are emitted by the sensor and reflected by nearby objects. Using the travel time of the sound waves and the speed of sound, the sensor calculates the distance travelled and thus the distance to the object.
The data is transmitted to the corresponding backend via LoRaWAN®. The transmission interval can be individually configured via downlink OTA.
The weatherproof and robust housing in combination with the long battery life allows maintenance-free real-time monitoring for several years.
Areas of application:
Running water level
Flood monitoring
Waste water management
Snow level
Silo, waste and tank level
Performance features:
Ultrasonic sensor Measuring range: 50cm to 1000cm
Housing dimensions (L x W x H): 170mm x 81mm x 70mm
IP protection class: housing IP66/67; sensor IP67
Operating temperature: -20℃ to +50℃
Ambient humidity: 0% to 100% RH
Device class: Class A
Communication: LoRaWAN® standard
Activation: OTAA, ABP
Transmission power: +14dBm, ADR
Power supply: replaceable 2x alkaline C battery (LR14)
Battery life: 10.5 years (60min transmission interval, SF12)
Available frequency: EU868
Measuring interval: 10min, configurable
Manufacturer:
Decentlab
Tip
WILSEN wireless ultrasonic sensor WS-UCC4000
€392.90*
Wireless ultrasonic sensor with LoRaWAN® interface WS-UCC4000
The wireless ultrasonic sensor can be used for remote monitoring of fill level.The fill level, but also other parameters such as geo data and sensor status data, are measured or recorded in configurable time intervals andtransmitted to a counterpart in the LoRa network from where they are available for pure display or further processing.The sensor is parameterised via a Bluetooth interface using a mobile device (smartphone or tablet) and the WILSEN app belonging to the sensor.
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased WILSEN wireless ultrasonic sensor is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Battery powered
Data transmission via LoRaWAN
LoRaWAN downlink channel for querying and adjusting parameter values
Bluetooth interface for commissioning, parameterization and diagnostics
Manufacturer:
Pepperl+Fuchs
Tekelek TEK766 Ultrasonic Level Sensor LoRaWAN
€143.90*
Ultrasonic LoRaWAN Sensor Tek766 for tank level monitoring.
The LoRaWAN-based Tek766 is a battery powered, configurable ultrasonic level sensor with integrated wireless interface.
Use cases:
Monitoring of fill levels in tanks
Monitoring of fluid levels
Ensuring the continuous availability of fuels or other operating resources
Monitorable liquids:
Fuels
Heating oil
Kerosene
Water
Waste oil
and more
Benefits:
Accurate and reliable monitoring of tank levels
Alert when filling levels are below or exceeded
Optimization of procurement and delivery
Optimizing your logistics
Increase in process efficiency
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased Tekelek TEK766 Ultrasonic Level Sensor is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Technical characteristics:
Remote configuration
Easy installation
Up to 14 years of battery life
LoRaWAN radio interface (868 MHz)
Up to 15 km range
CE conformity and ROHS conformity
Manufacturer:
Tekelek
Netvox Door & window contact sensor (reed) R718F with LoRaWAN®
€99.00*
LoRaWAN® R718F Door & Window Contact Sensor (Reed) from Netvox for Monitoring Opening Conditions
The netvox R718F is equipped with a reed switch that can be used to detect the status "open" or "closed". Inside the magnetic range, the reed switch is switched on (conductive) and outside it is switched off (non-conductive). Thus, the module can detect the closing and opening signals. This makes the sensor ideal for monitoring doors and windows. Thanks to the built-in radio module, information and data can be sent wirelessly to the LoRaWAN® gateway. The door and window contact sensor is battery-operated and has low energy consumption.
Areas of application:
Monitoring of doors, windows and garage doors
Tracking of production lines
Manufacturer:
Netvox
%
SENSATIVE Strips Multisensor +Drip for LoRaWAN®
€59.90*
€99.95*
(40.07% saved)
SENSATIVE Strips Multisensor MS +Drip for LoRaWAN®
The Strips Multisensor +Drip from SENSATIVE has several promising applications and is the ideal choice for a professional indoor IoT application. Due to its ultra-slim shape, the sensor can be mounted almost anywhere. The minimalist design as well as the easy installation and long battery life, make the Strips the go-to sensor for architects and design-conscious users.
Ex works, the sensor detects water leakage and can send alarm messages accordingly via IoT Plattforms like B.ONE Gallery. It also measures the ambient temperature to warn of frost if necessary.In addition, the integrated magnetic sensor for monitoring doors and windows and the brightness sensor (LUX) can be activated.The data and measured values are transmitted to the corresponding backend via LoRaWAN®.
NOW NEW OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased SENSATIVE Strips Multisensor+Drip is directly created in the MZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Areas of application:
Smart Home
Smart Office
Smart School
Smart Building
Performance features:
Model: Strips MS +Drip
Measurement parameters:
Humidity detection / flooding alert (water leakage)
Temperature: +/- 0.24°C
Configurable: Magnetic sensor (door and window), Ambient light: 1-64000 LUX
Dimensons: 195mm x 15mm x 3mm
Operating conditions: -30°C to +60°C
Application area: Indoor
LoRaWAN® device class: Class A
Activation: OTAA
Configuration: Downlink
Frequency: Europe (863-870 MHz)
Transmit power: +14dBm
Transmission interval: configurable
Power supply: built-in LiMnO2 battery
Battery replaceable: no
Battery life: up to 10 years (Battery Calculator)
Accessories: +Switch, +Clip
Manufacturer:
Sensative
Netvox Water Leakage Sensor R311W Class A with LoRaWAN®
€57.95*
R311W LoRaWAN® Leakage Sensor from Netvox to Prevent Water Damage
The Netvox R311W sensor is a LoRaWAN® class A device and enables the detection of water leaks. As soon as the sensor detects a leak, it sends an immediate message to the connected backend. With ZENNER's ELEMENT IoT platform, you can thus receive an immediate email via the alarm and control management and avoid major water damage.
Thanks to its small form factor, the device can be installed inconspicuously in almost any location.
Areas of application:
Data centers
Machine and server rooms
Pipelines in basements
Sanitary facilities
Keel rooms of ships
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased Netvox R311W is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Manufacturer:
Netvox
%
Tip
.png "ZENNER CO2 INDICATOR L868 ID A for LoRaWAN®")
ZENNER CO2 INDICATOR L868 ID A for LoRaWAN®
€52.90*
€99.90*
(47.05% saved)
ZENNER CO2 INDICATOR L868 ID A for LoRaWAN®
The ZENNER CO2 INDICATOR is a compact indoor LoRaWAN® radio sensor (868MHz) for measuring the CO2 content of indoor air. This product uses the photoacoustic principle to detect the CO2 concentration (ppm) in real time, enabling more efficient ventilation behaviour and faster response time. With the integrated display and the colour-changing LED display, the sensor always provides real-time information about the current CO2 value, the battery level and the status of the LoRaWAN® connection. An optimal stationary and mobile companion in the company, at the workplace, in the meeting room at a meeting or in the canteen. It can be placed on any flat surface. In addition, the device can also be used "stand alone", i.e. without a LoRaWAN® connection, e.g. at a meeting outside the company, when visiting a customer or a restaurant outside the range of the LoRaWAN® network. Without LoRaWAN® connection, however, no remote monitoring or alarming can take place. The CO2 limits can be set individually by radio command (downlink). The device can be operated with the integrated rechargeable battery or permanently powered by a standard USB-A power supply unit 5V. Please note that only the USB-A to USB-C charging cable is included, a power supply unit is also required.
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased ZENNER CO2 Indicator is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the ZENNER CO2 Indicator data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
NOW NEW also available and expandable within the Actillity ZENNER DataCake Starterkit on ThingPARK.
Download CO2 Sensor Actility ZENNER Datacake Bundle
Link to ThingPARK Actility ZENNER DataCake AirQuality Solution
Use Cases
Indoor Air Quality
Smart Building
Smart School
Smart Office
Smart Home
Product Features
Modern design
Display with CO2 indication (ppm) as well as quality of LoRaWAN connection and battery status
LED traffic light
Integrated battery
Configuration Over the Air (OTA)
Evaluation of the CO2 measured values
Range (ex works)
Evaluation
LED Farbe
< 800ppm
normal
green
800 – 999ppm
slightly increased
yellow
1.000 – 1.399ppm
high
purple
> 1.399ppm
very high
red
The measuring ranges can be set individually via LoRaWAN® downlink.
Specifications
Model
CO2 INDICATOR L868 ID A
Weight
115g
Size
63,6 x 46,0 x 54,6mm
Display Size
59,9 x 49,9mm
LoRaWAN®
Klasse A
Frequency
863 ~ 870MHz
Transmit Power
max. 14dBm
Battery
2.000mAh
Power Input
5V⎓ 1A (Hinweis: im Lieferumfang ist kein Netzteil enthalten)
Operating Temperature
0 ~ 40℃
Operating Humidity
0 ~ 99%rH (nicht kondensierende Umgebung)
CO2 Measuring Range
400 ~ 9.999ppm
Accuracy of
400 ~ 2.000ppm --> ±50ppm
Accuracy of
2.000 ~ 9.999ppm --> no guarantee
Scope of Delivery
ZENNER CO2 Indicator L868 ID A for LoRaWAN
User Manual
USB-A to USB-C Cabel
Notice: There is no 5V power supply included in the delivery. You can use a commercially available smartphone USB-A power adapter, for this purpose.
Manufacturer:
ZENNER
%
SENSATIVE Strips Presence for LoRaWAN®
€54.90*
€99.95*
(45.07% saved)
SENSATIVE Strips Presence for LoRaWAN®
The Strips Presence by SENSATIVE is an ultra-thin (3mm) active IR occupancy sensor for offices and buildings. The sensor monitors e.g. desk occupancy by measuring objects and people at close range (configurable up to 50cm). The minimalist design as well as the easy installation (adhesive back) and long battery life, make the Strips the go-to sensor for architects and design-conscious users. The active IR sensor is activated ex works. In addition, the integrated magnetic sensor can be activated to monitor doors and windows.
The data and measured values are transmitted to the corresponding backend via LoRaWAN®.
OPTIONAL with ZENNER IoT PLUG&PLAY booking-in services:
Simply selsect one of the two ZENNER IoT PLUG&PLAY booking-in options to the right of the product image by clicking on the selection box. Selecting the log-in service ensures that your purchased SENSATIVE Strips Presence is directly created in the ZC LoRaWAN®-Netz EUROPE and optionally also automatically added to your B.One Gallery visualisation platform. Without manual configuration, setup and authentication. Prerequisite for visualisation: You already have a ZENNER IoT GatewayPLUS SMART, ZENNER IoT GatewayPLUS Indoor or Outdoor with the IoT PLUG&PLAY Option selected in uses.
Order, plug in, switch on and view the sensor data in your B.One Gallery. See the measurement data, actions and progressions of your sensor directly there. Design and view your graphics, charts and reports. Create graphical reports of your data and share them with your colleagues, partners, customers or service providers simply via WebLink. The reports can be updated and the recipients only need a web browser
Areas of application:
Smart Office
Smart School
Smart Building
Smart Home
Performance features:
Model: Strips Presence
Measurement parameters:
Active IR (infrared) occupancy sensor
Configurable: magnetic sensor (door and window)
Dimension: 195mm x 15mm x 3mm
Operating conditions: -30°C to +60°C
Application area: Indoor
Mounting: adhesive backside
LoRaWAN® device class: Class A
Activation: OTAA
Configuration: Downlink
Frequency: Europe (863-870 MHz)
Transmit power: +14dBm
Transmission interval: configurable
Power supply: built-in LiMnO2 battery
Battery replaceable: no
Battery life: up to 10 years (Battery Calculator)
Accessories: +Switch, +Clip
Manufacturer:
Sensative
ELSYS ERS LoRaWAN multi-room sensor for indoor climate, light and motion measurement
€70.00*
Low cost LoRaWAN sensor from ELSYS for indoor environment monitoring
A LoRaWAN room sensor for measuring the indoor climate (temperature, humidity), light and motion (PIR), in an inconspicuous housing for simple wall mounting.
Manufacturer:
ELSYS
ELSYS EMS Door LoRaWAN door and window contact sensor
€59.00*
LoRaWAN® sensor for indoor opening activity
The EMS Door Sensor from ELSYS detects opening activities and movements (accelerometer).
Due to the very minimalistic and compact design, the sensor can be easily mounted on doors, windows, cabinets, etc. with the adhesive strips already attached. This makes the sensor ideal for a wide range of applications:
Smart Buildings
Workplace Management
Recognition of opening activities
Motion detection
Like all Elsys sensors, this one can be configured easily and quickly via NFC (Sensor Settings App) or over the air (OTA) via downlink.
The sensor requires a 3.6V AA lithium battery for power supply. This battery is not included in the scope of delivery and must be ordered separately (see accessories).
Manufacturer:
ELSYS
ELSYS ERS Eye wireless Multi room sensor for indoor climate, light, motion and occupancy measurement
€119.00*
Versatile LoRaWAN room sensor from ELSYS for indoor environment and occupany monitoring
ERS Eye is a LoRaWAN sensor that measures indoor climate (temperature and humidity), light, motion and room occupancy. ERS Eye is intended for mounting on a ceiling or wall. It detects the presence of body heat in the room by measuring the temperature in an 8×8 matrix with a viewing angle of 60×60 degrees. It can be used, for example, for dynamic workplace management and workplace statistics.
Manufacturer:
ELSYS
%
ELSYS ERS CO2 Lite wireless multi-room sensor for air quality measurement
€139.00*
€169.00*
(17.75% saved)
previously €169.00*
LoRaWAN CO2 Sensor from ELSYS for indoor climate monitoring
A LoRaWAN room sensor to measure the indoor climate (CO2, temperature, humidity) in an inconspicuous housing for easy wall mounting.
Compared to the ERS CO2 sensor, the ELSYS ERS CO2 Lite does not need to detect brightness and movement and is therefore the ideal sensor for measuring the indoor climate.
Manufacturer:
ELSYS
previously €169.00*
ELSYS ERS Lite wireless Multi room sensor for indoor climate measurement
€58.00*
Low cost LoRaWAN sensor from ELSYS for indoor climate monitoring
The ELSYS ERS Lite is an affordable LoRaWAN room sensor for measuring the indoor climate (temperature and humidity) in an unobtrusive housing for easy wall mounting.
Manufacturer:
ELSYS
WATTECO Outdoor Remote Temperature Sensor LoRaWAN®
€112.00*
LoRaWAN® Outdoor Remote Temperature Sensor from WATTECO
Sensor with remote temperature probe.
The Remote Temperature Sensor from WATTECO is a robust, battery-powered sensor for real-time transmission of temperature measurements over long distances via LoRaWAN®. Transmission of extensive area measurements, e.g. cold chains, refrigerated transports, smart buildings, industrial plants. Periodic transmission of the sensor values and/or alarm in case of exceeding or falling below the limit values.
Use Cases:
HVAC
Monitoring of cooling suuply chains and refrigerated transporters
Warehouse logistics with temperature-sensitive products
Industrial processes (machinery, plant engineering)
Data center / IT server room
Technical specifications:
Probe with 5m cable and metal tip
Measuring range -40°C +90°C
Precision -/+ 1°C - 30°C a +60°C
Batch reporting via data compression
IP55
CE Compliant & RoHS Compliant
Per request available with 2 measuring probes.
RF TRANSCEIVER
Frequency (MHz) EU: 863-870
Transmit Power (dBm) +14
Receiver Sensitivity (dBm) -140
FIRMWARE
Protocol: LoRaWAN®, Class A
Measurement Cycles from 1h to 48h in 1h step
Data history available
Activation method:
Activation by Personalization (ABP)
Over-The-Air Activation (OTAA)
Data encryption: AES128
TEMPERATURE MEASURE
Range -40 / +90
Accuracy +/- 1°C over the range [-20°C; +40°C]
Resolution 0.2°C
OUTPUT CHARACTERISTICS
4-20mA gauge voltage supply (V): 10
0-10V gauge voltage supply (V): 14
POWER
Power supply:
3,6V / 3600mAh lithium battery
12 years: Data compressed / 1 measure per hour / 1 transmission per day
9 years: Data not compressed / 1 measure per hour / 1 transmission per day
INTERFACE
Buzzer Indicator: Network pairing & configuration
Magnetic switch: Reset, ON/OFF
MECHANICAL FEATURES
Dimension (mm): 84x82x55
IP Class: IP55
DIRECTIVES & STANDARDS
EN, 61000-4-2 EN 300-220-1 V2-4-1, EN 301 489 V1-6-1 CE, FCC part 15.247 subpart C, RoHS recommendation compliant
Manufacturer:
WATTECO
