2 lithium batteries for powering LoRaWAN® devices with 1.5VThese high-quality lithium batteries provide LoRaWAN devices with reliable power autonomously for several years. They weigh 1/3 less than standard alkaline batteries and are leak-proof.Technical specifications:Nominal voltage: 1.5V Nominal capacity: 3000mAh Operating temperature: - 40°C to + 60°C Diameter: 14mm
Length: 50,5mm Illustration may vary.
DIN rail adapter for CleverCity Greenbox Compact 3.
With the DIN rail adapter, you can optionally and if necessary also mount the Greenbox Compact 3 on a DIN rail - for example in a distribution box.
This mounting variant is often used when the device is used for string control. The adapter is attached to the back of the Greenbox with the four screws supplied.
LoRaWAN mast antenna for CleverCity Greenbox Compact 3.
For the safest possible operation or to ensure the best possible radio reception, we recommend an additional antenna for the Greenbox compact, which is used for single mast control.
The mast antenna secures the connection between the LoRaWAN network and the green box built into the street lighting mast.
The antenna is mounted flush on the mast with just one drill hole and secured with the enclosed strap. A foam rubber seals the antenna and prevents against moisture penetrating.
Technical data:
Frequency
865 ... 880MHz
Amplification
0dBd (2dBi), typically
Protection class
IP66
Polarization
linearly
Sending power RMS
< 10W
Temperature range
-40°C ... +85°C
UV-protection
> 10 years
Material
ABS
Cable length
ca. 4m
Weight
ca. 100g
Dimensions
150x38x36mm
Fixing belt
Mast diameter 80 to 140mm
LoRaWAN® Angle Antenna (SMA) for CleverCity Greenbox Compact 3.
For the safest possible operation or to ensure the best possible radio reception, we recommend an additional antenna for each Greenbox Compact 3, which is used for single mast control.
The angled rod antenna with SMA connector ensures the connection between the LoRaWAN® network and the GreenBox Compact 3.
It is used in plastic switch boxes, house installations etc. It is screwed directly onto the GreenBox.
LoRaWAN Configuration Cable for Digital Matter Yabby Asset Tracker.
Due to the small form factor of the Yabby Asset Tracker a special adapter is needed for configuration via USB.
Included in delivery:
USB Cable
Adapter board
Connector cable
ELSYS lithium battery for IoT sensors of the ESM series.
Special battery suitable among others for the ELSYS ESM5k multi-sensor for measuring air quality, light and acceleration (see following tab "Accessories").
Technical Data:
Model designation: ER14250
Nominal voltage: 3.6V
Capacity: 1200 mAh
Weight: 10 g
Dimensions (H x W): 25.5 x 15 mm
also suitable as replacement battery for HCB ER14250M 1/2AA 3.6V
Figure may differ.
Lithium battery to power LoRaWAN® devices
This lithium battery from ELSYS reliably supplies LoRaWAN devices of the ERS and EMS series autonomously with power for several years.
Manufacturer:
ELSYS
€7.90*
