WILSEN wireless ultrasonic sensor UCC2500
Fill level sensor Wilsen UCC2500 P+F L868 OD A
The
ultrasonic wireless sensor from Pepperl + Fuchs is specially designed for level
monitoring in tanks and silos. With a detection range of 150 to 2500 mm and an
impressive resolution of 1 mm, it offers precise measurements for a wide range
of applications.
Main Features:
- Battery operated: For maximum flexibility and easy installation.
- Data transmission via LoRaWAN: Enables reliable and efficient remote monitoring.
- LoRaWAN downlink channel: This channel allows parameter values to be queried and adjusted directly from the LoRa network, enabling convenient remote control and monitoring.
- Bluetooth interface: Ideal for commissioning, parameterization and diagnostics. Easy connection with mobile devices such as smartphones or tablets.
- WILSEN app support: Conveniently parameterize the sensor via the associated WILSEN app on your mobile device.
Function:
The ultrasonic wireless sensor is used for remote monitoring of fill levels, water levels and distances. It records the aforementioned measured variables as well as other measurement and status data at adjustable time intervals and transmits them to the remote station in the LoRa network. The data can be displayed or further processed there. Thanks to the sensor's downlink channel, you can access the sensor remotely to retrieve measurement data or adjust the sensor parameter values.
Manufacturer "Pepperl+Fuchs"
Pepperl+Fuchs offers a wide product range of industrial sensors and process interfaces - from the supply of standard components to the planning and design of complex application solutions.
