PlacePod solves the most mission-critical aspects of parking managementACCURATE, REAL-TIME VEHICLE DETECTION AND THE LOCATION OF AVAILABLE PARKING SPACES.PlacePod is an surface-mounted sensor that communicates with a gateway to provide real-time parking data over a Low Power Wide Area Network (LPWAN). It provides accurate vehicle detection in parking spaces, up to 7 years of battery life, and is stable over temperature fluctuations, even in harsh environments.Incorporating real-time parking data from PlacePod smart parking sensors into a parking management strategy can help reduce traffic congestion and carbon emissions, foster economic development and improve urban mobility, and increase parking revenue. FEATURES & BENEFITSIncludes the industry’s most accurate magnetic sensing system for vehicle detection with the combination of PNI’s high-performance magnetic sensor and vehicle detection algorithms that accurately detect the presence or absence of a car in a parking space. PlacePod vehicle detection algorithms offer machine learning capability. This unique feature provides improved accuracy when filtering out local electromagnetic interference and changes in the local magnetic field. Improved vehicle detection algorithms and continuous monitoring provide more accurate detection for vehicles in neighboring parking spaces. This is ideal for space-constrained or narrow parking spaces. With its auto-calibration feature, PlacePod does not require any calibration during installation or when firmware is updated. Calibration is optional. This saves time during installation and lowers total cost of ownership of the system. Unlike other parking sensors, PlacePod provides continuous vehicle detection without missing a parking event. Capability for wireless configuration and software updates using Bluetooth Low Energy (BLE) via PNI’s mobile iOS and Android applications. Unlike other magnetic sensor-based parking sensors, PlacePod accurately detects parking events in dense urban environments and filters out electromagnetic interference or “noise” such as direct current from overhead power lines, interference from underground trains, or transient magnetic signatures from passing traffic, which can trigger false parking events. Customers can visualize parking data using PNI’s Parking Management Application – a comprehensive dashboard for managing and monitoring all parking resources and data, including installation and verification, diagnostics, monitoring, and reporting. Using the PlacePod API, data can be shared with 3rd-party applications (including IoT platforms, parking enforcement, mobile payment, parking management systems, parking guidance systems). Includes a built-in LoRa® radio that communicates to a gateway or base station with complete Low Power Wide Area Network (LPWAN) compatibility. Specifications Communication LoRa 915 MHz, 868 MHz, 923 MHz, 865 MHz Module LoRaWAN™ compliant Uses Sub-GHz ISM bands in North America, Europe and other regions LoRaWAN Device Type Class A Outputs 2 states: Occupied Vacant Battery Life/Type Up to seven years depending on configuration and distance from gateway Lithium-Thionyl Chloride Dimensions In-Ground 4.3 in (10.92 cm) diameter -minimum hole 4.5 in (11.43 cm) 1.18 in (3.0 cm) height -minimum hole 2.5 in (6.35 cm) Dimensions Surface-Mount 9.0 in (22.86 cm) diameter 1.25 in (3.15 cm) height Installation Position Center of the parking space Operating Temperature -30°C to +70°C / -22°F to +158°F Storage Temperature -40°C to +85°C / -40°F to +185°F Activation Type OTAA Certifications FCC (915 MHz), CE (868 MHz)

Parking sensor LoRaWAN 868 PNI PlacePod InGround ODPlacePod solves the most mission-critical aspects of parking management ACCURATE, REAL-TIME VEHICLE DETECTION AND THE LOCATION OF AVAILABLE PARKING SPACES.PlacePod  InGround is an in-ground mounted sensor that communicates with a gateway to provide real-time parking data over a Low Power Wide Area Network (LPWAN). It provides accurate vehicle detection in parking spaces, up to 7 years of battery life, and is stable over temperature fluctuations, even in harsh environments.Incorporating real-time parking data from PlacePod smart parking sensors into a parking management strategy can help reduce traffic congestion and carbon emissions, foster economic development and improve urban mobility, and increase parking revenue.FEATURES & BENEFITSIncludes the industry’s most accurate magnetic sensing system for vehicle detection with the combination of PNI’s high-performance magnetic sensor and vehicle detection algorithms that accurately detect the presence or absence of a car in a parking space. PlacePod vehicle detection algorithms offer machine learning capability. This unique feature provides improved accuracy when filtering out local electromagnetic interference and changes in the local magnetic field. Improved vehicle detection algorithms and continuous monitoring provide more accurate detection for vehicles in neighboring parking spaces. This is ideal for space-constrained or narrow parking spaces. With its auto-calibration feature, PlacePod does not require any calibration during installation or when firmware is updated. Calibration is optional. This saves time during installation and lowers total cost of ownership of the system. Unlike other parking sensors, PlacePod provides continuous vehicle detection without missing a parking event. Capability for wireless configuration and software updates using Bluetooth Low Energy (BLE) via PNI’s mobile iOS and Android applications. Unlike other magnetic sensor-based parking sensors, PlacePod accurately detects parking events in dense urban environments and filters out electromagnetic interference or “noise” such as direct current from overhead power lines, interference from underground trains, or transient magnetic signatures from passing traffic, which can trigger false parking events. Customers can visualize parking data using PNI’s Parking Management Application – a comprehensive dashboard for managing and monitoring all parking resources and data, including installation and verification, diagnostics, monitoring, and reporting. Using the PlacePod API, data can be shared with 3rd-party applications (including IoT platforms, parking enforcement, mobile payment, parking management systems, parking guidance systems). Includes a built-in LoRa® radio that communicates to a gateway or base station with complete Low Power Wide Area Network (LPWAN) compatibility. Specifications Communication LoRa 915 MHz, 868 MHz, 923 MHz, 865 MHz Module LoRaWAN™ compliant Uses Sub-GHz ISM bands in North America, Europe and other regions LoRaWAN Device Type Class A Outputs 2 states: Occupied Vacant Battery Life/Type Up to seven years depending on configuration and distance from gateway Lithium-Thionyl Chloride Dimensions In-Ground 4.3 in (10.92 cm) diameter -minimum hole 4.5 in (11.43 cm) 1.18 in (3.0 cm) height -minimum hole 2.5 in (6.35 cm) Dimensions Surface-Mount 9.0 in (22.86 cm) diameter 1.25 in (3.15 cm) height Installation Position Center of the parking space Operating Temperature -30°C to +70°C / -22°F to +158°F Storage Temperature -40°C to +85°C / -40°F to +185°F Activation Type OTAA Certifications FCC (915 MHz), CE (868 MHz)

The LoRaWAN® Parksensor from Parklab is designed to reliably determine whether a parking space is occupied or available.The wireless LoRaWAN® parking sensor, with its radio capability, detects and reports parking space occupancy and enables active parking management, such as search, navigation, and reservations. Critical parking areas, such as disabled parking spaces, access routes, emergency exits, and electric vehicle charging stations, can be reliably monitored. This simple solution for upgrading off-street parking can be installed in just minutes. Smart parking significantly improves guidance systems and reduces the time spent searching for parking spaces. Furthermore, using parking sensors at electric vehicle charging stations can prevent unauthorized use of these spaces.Technical data:LoRa 433/868/923MHzDetection range up to 200 cmDetection rate 95-99%10-15 second response timeReplaceable lithium batteries (minimum 5-6 year lifespan)Adhesive/screw mounting ,on or into the floorDimensions 173mm x 39mmIP68 protection ratingSuitable for all weather working conditionsOperating temperatures: from -45°C to 85°C<Note - to activate this sensor, there is needed a USB dongle, available in store under part number 189457 Ac USB Dongle Parklab Sensor Activation!

The Parklab AC USB dongle is a service tool that has been specially developed for use with Parklab GmbH's advanced parking space occupancy sensors. This compact device serves as a communication interface (short-range radio) and enables wireless activation, configuration and diagnosis of surface-mounted sensors.The device enables: Quick switching of sensors from energy-saving mode (deep sleep) to active monitoring modeWireless configurationPrecise diagnostics: Thanks to the special Parklab software, the dongle enables real-time reading of the sensors' operating parameters, checking of the battery charge level and verification of the LPWAN network signal strength (LoRaWAN/NB-IoT)Plug & play Technical data: USB Type A (PC/tablet compatible)Short-range radio (for local configuration)Power supply directly via the USB port (5 V)Compatibility: Parklab series sensors
